  • Page 1: Table Of Contents

    Introduction Installation Operation Suggestion On Food storage Care and Maintenance Trouble Shooting To Reverse the Doors Table of Contents Registration Important Safety Instruction Identification of Parts Installation Starting Temperature Control Refrigerator Freezer Function Super Freezer Vacation Lock Memory Feature Door Alarm Self Test Ice Making Defrosting...

  • Page 2: Important Safety Instruction

    Introduction Registration Introduction The model and serial number are found on the rear of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.

  • Page 3

    Important Safety Instruction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power The dedicated outlet should be used.

  • Page 4

    Introduction Important Safety Instruction Do not pull out the cord or touch the power plug with wet hands. • It may cause electric shock or injury. Remove water or dust from the power plug and insert it with the ends of the pins securely connected.

  • Page 5

    Important Safety Instruction Water tank can fill with potable water only. Do not install the fridge-freezer in the wet place or the place which water or rain splashes. Deterioration of insulation of electric parts may cause electric leakage. Do not use or store inflammable materials ether, benzene, alcohol, medicine, LP gas, spray or cosmetics near or in the fridge-freezer.

  • Page 6

    Introduction Important Safety Instruction Avoid the heating devices. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the fridge-freezer. It may cause fire, electric shock or injury by dropping down. Use the submerged fridge-freezer after checking it. It may cause electric shock or fire.

  • Page 7

    Important Safety Instruction When any strange smell or smoke is detected from the fridge-freezer, disconnect the power plug immediately and contact to the service center. It may cause fire. Do not allow any person except the qualified engineer to disassemble, repair or alter the fridge- freezer.

  • Page 8

    Introduction Important Safety Instruction Do not insert the hands or the metal stick into the exit of cool air, the cover, the bottom of the fridge- freezer, the heatproof grill (exhaust hole) at the backside. It may cause electric shock or injury. When you want to dispose the fridge-freezer, contact to the down-block office.

  • Page 9

    Important Safety Instruction Do not install the fridge-freezer in the wet place or the place which water or rain splashes. Deterioration of insulation of electric parts may cause electric leakage. Do not insert the hands into the bottom of the fridge-freezer.

  • Page 10

    Introduction Important Safety Instruction WARNING Precaution • This fridge-freezer must be properly installed and located in accordance with the Installation Instruction before it is used. • Never unplug your fridge-freezer by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet.

  • Page 11

    Important Safety Instruction • Do not disassemble, repair or alter the appliance. It may cause fire or abnormal operations, which may lead to injury. • Pull the power plug out of the socket before replacing the interior light in the refrigerator. Otherwise, there is a risk of electric shock.

  • Page 12

    Introduction Important Safety Instruction Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

  • Page 13

    Important Safety Instruction • If the wall socket is loose, do not insert the power plug. It may cause electric shock or fire. • Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull it straight out from the outlet.

  • Page 14: Identification Of Parts

    Introduction Removable Glass Shelf Lamp Multi-air Flow Duct Meat Tray (Optional) Refrigerator Temperature Control Vegetable Drawer Used to keep fruits and vegetables, etc. fresh and crisp. (1 or 2) Ice Cube Tray Freezer Compartment Removable Plinth Note Identification of Parts If you find some parts missing from your unit, they may be parts only used in other models.

  • Page 15: Installation Installation

    Installation Select a good location. Place your fridge-freezer where it is easy to use. Avoid placing the unit near heat sources, direct sunlight or moisture. There must be proper air circulation around your fridge-freezer to keep it operating efficiently. To avoid vibration, the unit must be leveled. If required, adjust the leveling screws to compensate for the uneven floor.

  • Page 16: Operation Temperature Control

    Operation Temperature Control Your fridge-freezer has two controls that let you regulate the temperature in the fridge and freezer compartments. Refrigerator • Initially set the TEMP. CONTROL at "4". Then adjust the compartment temperature according to your desire. • If you want an inside temperature slightly less cold or colder, turn the knob towards WARM or COLD, respectively.

  • Page 17

    • You can now adjust the temperature of the compartment as you want. • When you press the temperature control buttons, the temperature of Freezer compartment is repeated in the following order. LED 88 Type Freezer Compartment : -19°C → -20°C → -21°C → -22°C → -23°C → -15°C →...

  • Page 18: Function

    Operation Function Super Freezer • Please select this function for prompt freezer. • This function is used when you want to freeze the foods quickly. Press the ‘SUPER FRZ.’ (Super Freezer) button once, and then the quick freeze operation starts with the lamp on.

  • Page 19: Lock

    Lock • Pressing this button stops operation of other buttons. • ”Locking” or “Un-Locking” is repeated whenever pressing the ‘CHILD LOCK’ button. (For “Locking” or “Un-Locking” press the ‘CHILD LOCK’ button for 2 secs.) • When ‘CHILD LOCK’ is activated, pressing the other buttons would not work.

  • Page 20: Water Dispenser

    Operation Water Dispenser Features WATER LEVEL WATER LEVEL Install • Please assemble the VALVE ASSEMBLY after correctly adjusting it with a DOOR HOLE.

  • Page 21

    Filling of After turning the HANDLE Tank backward with the WATER TANK WATER TANK installed at the DOOR, Open the CAP TANK (SMALL) and then fill water using a kettle etc. * Fill water while watching a sight glass on the front of the WATER TANK.

  • Page 22: Suggestion On Storing Food

    Suggestions on food storage Storing Food Note Storing Food • Do not store food which goes bad easily at low temperature, such as banana, and melon. • Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other food, and lead to higher electric bills.

  • Page 23: General Information

    General Information Power Failure • 1~2 hour power failure does no harm to the foods stores. Try to avoid opening and closing the door too frequently. If You Move • Take out foods from the fridge-freezer and firmly fix the loose items with tape. •...

  • Page 24: Cleaning

    Care and Maintenance Before Cleaning Exterior Interior After Cleaning Cleaning Be sure to unplug the power. Clean the outside of the fridge-freezer with a soft cloth soaked with hot water or liquid detergent. If you use a detergent, be sure to wipe it with a clean wet cloth. As above.

  • Page 25

    GRILLE and DRIP TRAY Exterior Dispenser WATER TANK CAP TANK (Big & Small) VALVE ASSEMBLY Care and Maintenance Remove the GRILLE , wipe moisture out around the DOOR part and the DRIP TRAY using a clean cloth. Wipe moisture etc out outside of Dispenser and on the DISPENSER PAD using a cloth.

  • Page 26: Trouble Shooting

    Trouble Shooting Problem Fridge-Freezer does not operate Fridge or Freezer Compartment Temperature too warm Vibration or Rattling or Abnormal Noise Frost or Ice Crystals on frozen Food Moisture forms on Cabinet Surface Trouble Shooting Before calling for service, check this list. It may save you both time and expense.

  • Page 27

    Problem Possible Causes Moisture collects • Too frequent or too long door openings. inside • In humid weather, air carries moisture into fridge • Foods with strong odors should be tightly Fridge has odor • Check for spoiled food. • Interior needs cleaning. Door not closing •...

  • Page 28: Precaution

    To Reverse the Doors Your fridge-freezer is designed with reversible doors,so that they may open from either the left or right hand side to suit your kitchen design. Precaution Before reversing the door, first of all,you should take out food and accessories like shelves or trays which are not fixed in the fridge-freezer.

  • Page 29

    Loosen the bolt of the Hinge Middle Middle , and lift up the freezer door (When separating the refrigerator door, separate the bush together.)Separate the hinge cover and set it on the separated part of middle hinge . After unscrewing the screw connected to the bottom cover connect the cover cap on the right side.

  • Page 30

    Memo...
