CHAPTER
5

Connecting the SmarTrax Hydraulic Valve

Locate the connector labeled 'LEFT' on the SmarTrax valve cable harness (P/N 115-4001-002).
1.
Insert the connector labeled 'LEFT' to the bottom solenoid installed in port '2' on the SmarTrax hydraulic
2.
valve. See Figure 4, "Cable Harness Installation Schematic," on page 21.
Repeat step 1 and step 2 to connect the 'RIGHT' connector to the top solenoid on port '2'.
3.
Locate the connector labeled 'Double Blocker 1 and 2' on the SmarTrax valve cable harness. Insert the
4.
connectors into the '1A and 1B' solenoids.

Connecting the Pressure Transducer

On the valve cable harness (P/N 115-4001-002), identify the connector labeled 'PSI'.
1.
Connect the 'PSI' connector to the pressure transducer using the provided di-electric if necessary.
2.
Manual No. 016-4001-084
W iring and Electrical
C h a p t e r 5
Connections
CAUTION
Ensure that the power cable is the last cable
connected.
Do not reverse the power leads. Doing so will
cause severe damage to the equipment.
Ensure the leads are connected to the correct
polarity.
17
