Technical data
6.8

Electrical data

WARNING!
Only circuits with limited power may be used for UL approved
components according to "NEC Class 2".
6.8.1 Electrical data, without fieldbus
communication
Protection class III as per DIN EN 61140 (VDE 0140-1)
Connections C ircular plug-in connector
(M12 x 1, 8-pin)
Operating voltage 2 4 V DC ± 25%,
max. residual ripple 10 %
Current consumption max. 150 mA
Power consumption max. 3.5 W
Input resistance for
set-point value signal 7 5 Ω at 0/4 – 20 mA / 12 bit resolution
Analogue position
feedback max. load
for current output
0/4 – 20 mA 560 Ω
Digital input 0 – 5 V = log "0", 12 – 30 V = log "1"
inverted input in reverse order
Communications
interface C onnection to PC
via USB-büS interface set
Communication
software Bürkert Communicator
6.8.2 Electrical data, IO-Link
Protection class I II as per DIN EN 61140 (VDE 0140-1)
Connection C ircular plug-in connector M12 x 1,
5-pin, A-coded, Port Class B
Operating voltage
System supply
(Pin 1+3) 24 V DC ±25 %
(according to specification)
Actuator supply
(Pin 2+5) 24 V DC ±25 %
1)
(according to specification)
Current consumption
System supply
(Pin 1+3) max. 50 mA
Actuator supply
(Pin 2+5) m ax. 100 mA
Total
power consumption max. 3.5 W
3) Actuator supply is galvanically isolated from system supply in accor-
dance with IEC 60664 and for electrical safety in accordance with
SELV from IEC 61010-2-201
