Type 8696 REV.2
Control and display elements
Manual LED
Color Status Description
is lit Operating state HAND active
red
is not lit Operating state AUTOMATIC active
red
Tab. 12: Manual LED
Charact LED
Color Status Description
green is lit CHARACT active
is not lit CHARACT inactive
green
Tab. 13: Charact LED
11.3.1 Status indicator
The status LED (RGB) show the device status.
The user can set the following LED modes for the display of
device status and valve position.
• Valve mode
• Valve mode with warnings (factory setting)
• NAMUR mode
• Fixed color
• LED off
The LED mode and the colors of the valve position can be set
with the Bürkert Communicator.
IO-Link:
The LED mode and the colors of the valve position can be also
set with an acyclic parameter (see parameter list).
The description for setting the LED mode can be found
in the section "Setting the LED mode, status indicator" in
the operating instruction.
Valve mode + warnings
Displays in valve mode + warnings:
• Valve position: open, half-way, closed
• Device status: failure, function check, out of specification,
maintenance required (according to NAMUR)
Valve position
Status, color
Open is lit yellow*
Half-way LED off*
Closed is lit green*
+ warnings, normal
Tab. 14: Valve mode
* F actorysetting,selectablecolorsforthevalveposition:Off,white,
green, blue, yellow, orange, red
english
Device status
Normal operation
--
--
--
operation
25
