Type 8696 REV.2

Technical data

6 TECHNICAL DATA
6.1

Conformity

In accordance with the EU Declaration of conformity, the posi-
tioner Type 8696 is compliant with the EU Directives.
6.2

Standards

The applied standards, which verify conformity with the EU
Directives, can be found on the EU-Type Examination Certificate
and / or the EU Declaration of Conformity.
6.3

Licenses

The product is approved for use in zone 2 and 22 in accordance
with ATEX directive 2014/34/EU category 3GD.
Observe instructions on operation in an explosion-risk (Ex)
area. Observe the ATEX additional instructions.
The product is cULus approved. Instructions for use in the UL
area see chapter "6.8 Electrical data".
6.4

Operating conditions

WARNING!
Solar radiation and temperature fluctuations may cause mal-
functions or leaks.
▶ If the device is used outdoors, do not expose it unprotected
to the weather conditions.
▶ Ensure that the permitted ambient temperature does not exceed
the maximum value or drop below the minimum value.
Ambient temperature
Degree of protection
Evaluated by the manufacturer:
IP65 / IP67 according to EN
60529
2)
Operating altitude:
2) Only if cables, plugs and sockets have been connected correctly and
in compliance with the exhaust air concept, see chapter "8 Pneumatic
installation".
6.5

Mechanical data

Dimensions See data sheet
Body material e xterior:
interior:
Sealing material EPDM / FKM
Stroke range
of valve spindle S eries 2103
and 23xx
Third-party devices
(modified guide
element required)
english
see type label
Evaluated by UL:
UL Type 4x Rating
2)
up to 2000 m above sea level
PPS, PC, stainless steel
PA6, ABS
3 – 32 mm
3 – 40 mm
9
