Menu Name Minimum Password to Read
(Menu Index) (None, User, Manager, Technician)
Set|Defrost
DefChkTmSpt:
DefChkTm:
ASHPDefTime:
DefTmr:
LwSctLnSpt:
LwSctLnDiffSpt:
DefInFanSpt:
OACoilTempSpt:
DefTmpDiff:
Set|Alarms
KeyRstFiltAl:
NetRstAls:
KeyRstAls:
FltrChgHrsSpt:
FltrChgHrsEn:
FltrChgHrs:
DATLLAlTmSpt:
ManAlTst:
AlmBOcfg:
NetRstFiltAl:
Serv|OpHours
FanRunTm:
CmpRunTm:
RstFanTm:
RstCmpTm:
ServiceMode:
ServiceTime:
RestartCt:
LastRstTyp:
Serv|SaveRestore
SaveCfsSel:
GetCfgsSel:
SaveUserRes:
SaveParams:
CfFileNumb:
AppDflts:
FactCfgStrg:
SDStatus:
RdWrStatus:
Serv|AnaIn
Serv|AnaIn|Status
aiDAT:
aiRAT:
aiOAT:
AnaIn10:
aiLWT:
AnaIn12:
CondOFlw:
AnaIn14:
OutAirFlw:
HdPress:
SptAdj:
RSSysMode
RSFanSpd:
SpcTmpTO:
HumIn:
HumOut:
LnVlt:
SpcTmp:
Serv|AnaIn|Config
CfgAnIn10:
CfgAnIn12:
CfgAnIn14:
Serv|AnaIn|Virtual
CO2:
RstVlts:
EWT:
OutCoilTmp:
InCoilTmp:
AVAILABLE
Serv|BinIn
OM 1280-2 • MICROTECH UNIT CONTROLLER
Minimum Password to Write
(None, User, Manager, Technician)
"RO" if Read Only
N
N
N
N
N
T
T
N
T
N
N
N
N
N
N
N
T
T
N
N
N
T
T
T
T
T
T
T
T
N
T
T
T
T
N
N
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
Appendix – Local User Interface (LUI)
Help Text
T How often to chk for defrst condition.
RO Time since last defrost cond check.
T ASHP defrost time setpt.
RO Defrost timer countdown.
T Low suction line temp alarm setpt.
T Low suct line temp alarm diff setpt.
T Indoor fan off when indoor coil > spt.
T Defrost ends when out coil>setpt+diff.
T Defrost ends outCoil>OACoilTempSpt+spt.
U Keypad reset filter alarm.
U Network reset alarms.
U Keypad reset alarms.
U Filter change alarm hours.
U Filter change alarm enable.
RO Current filter change hours.
U All htg on this long before DATLL Alr.
T Manually test an alarm.
T Alarm binary out when Flt/Prob or Flt.
U Network reset filter alarm.
RO Fan run time.
RO Compressor run time.
T Resets the total fan run time.
T Resets the total compressor run time.
T Speeds-up certain timers.
T How long unit remains in Service Mode.
T Number of controller restarts.
T Last controller reset type.
T Save configuration parameters.
T Get configuration parameters.
RO Save user configs to SD result.
T Manually save to non-volatile memory.
T SD file name: DaikinUnitVentXXX.
T Set all config params to app dflts.
RO Factory configuration string.
RO SD card is ready if status is Good.
RO Read write configs result.
RO Analog input discharge air temp.
RO Analog input return air temp.
RO Analog input outside air temp.
RO Analog input 10 counts.
RO Analog input leaving water temp.
RO Analog input 12 counts.
RO Condenser overflow value.
RO Analog input 14 counts.
RO Outside air flow value.
RO Head pressure.
RO Setpoint adjust temp.
RO Remote sensor system mode value.
RO Remote sensor fan speed mode value.
RO Space temp with tenant override.
RO Indoor humidity.
RO Outdoor humidity.
RO Line voltage.
RO Space temp without tenant override.
T Select virtual function for ai10.
T Select virtual function for ai12.
T Select virtual function for ai14.
RO CO2 virtual input.
RO Reset volts virtual input.
RO Entering water virtual temp.
RO Outdoor coil virtual temp.
RO Indoor coil virtual temp.
