Parameter (LUI)
EmergHtSpt
FBDPropGn
FBDIntgGn
EconPropGn
EconIntgGn
ClPropGn
ClIntgGn
ClMnPos
ClMxDeltaTmp
ClMxPos
HtPropGn
HtIntgGn
HtgMnPos
HtMxDeltTmp
HtMxPos
ElHtPropGn
ElHtIntgGn
CO2PropGn
CO2IntgGn
SZnVAVMxDelta
SZnVAVMnFan
SZnVAVMxFan
SZnVAVPropGn
SZnVAVIntgGn
OADLLPropGn
OADLLIntgGn
FanOffDel
FanCycling
CONTINUOUS, CYCLING (CONTINUOUS)
PWMLow
PWMMed
PWMHigh
FanRunTm
FltrChgHrs
BrkptAutoLow
BrkptAutoMed
BrkptAutoHi
BrkptAutoDiff
OM 1280-2 • MICROTECH UNIT CONTROLLER
Operating Range (Default)
0°F to 70°F
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
0% to 100%
1 to 10°F
10% to 100%
0.0 to 255.0
0.00 to 255.00
0% to 50%
1°F to 10°F
10% to 100%
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
0.0 to 255.0
1°F to 10°F
0% to 100%
0% to 100%
0 to 255
0 to 255
0.0 to 255.0
0.0 to 255.0
0 sec to 10 sec)
50% to 80%
70% to 90%
80% to 100%
0.0 hrs to 300,000.0 hrs
0 to 300,000.0 hours
5% to 100%
5% to 100%
5% to 100%
2% to 20% (2%)
UVC Configuration Parameters
ABV
Min
Max
Default
EHS
0
70
54
PI Parameters
0
255
10
0
255
1
0
255
1
0
255
0.1
0
255
0.5
0
255
0.02
0
100
20
1
10
5
10
100
100
0
255
0.5
0
255
0.02
0
50
0
1
10
5
10
100
100
0
255
8
0
255
0.5
0
255
1
0
255
0.01
1
10
5
0
100
5
0
100
100
0
255
0.1
0
255
0.01
0
255
2
0
255
0.2
Fan
0
10
4
0
1
0
50
80
75
70
90
90
80
100
100
0
300,000
0
300,000
5
100
5
5
100
75
5
100
95
2
20
2
48
Description
Emergency Heat Setpoint
Face and Bypass proportional PI loop
configuration
Face and Bypass integral PI loop configuration
Primary cool proportional gain
Primary cool integral Time
Hydro cooling valve proportional gain
Hydro cooling valve integral Time
Output when temperature delta is zero
The delta between control and target
temperatures to cause the valve to open 100%
Output when temperature delta is Max Delta
Temp
Heating Valve Proportional gain
Heating Valve Integral Time
Output when temperature delta is zero.
The delta between control and target
temperatures to cause the valve to open 100%.
Output when temperature delta is Max Delta
Temp.
Electric heat proportional gain
Electric heat integral time
OAD control for CO
proportional gain
2
OAD control for CO
Integral Time
2
Used with single zone VAV PI loop
Used with single zone VAV PI loop
Used with single zone VAV PI loop
Used with single zone VAV PI loop
Used with single zone VAV PI loop.
Configuration for PI loops proportional value
Configuration for PI loops integral value
Sets the space fan off delay
While not in unoccupied mode, this input
determines if the space fan may run
continuously without heating or cooling demand.
LonWorks Note: nciFanCycling: The fan
cycles when the cp is set to three, and the fan is
continuous when the cp is set to two
The percent speed for PWM low fixed speed
The percent speed for PWM medium fixed
speed
The percent speed for PWM high fixed speed
This output show the fan run time in hours. It
must have resolution of 0.1 hours and have a
range of at least 300,000 hours
Current filter change hours. Keeps track of the
number of hours that the fan has run with the
filter. This parameter is saved in non-volatile
memory
The percent speed transition point for low fan
The percent speed transition point for medium
fan
The percent speed transition point for high fan
The percent speed transition point differential.
This value is added when going up in speed
