- Page 1 INSTALLATION MANUAL CEILING CONCEALED CHILLED WATER FAN COIL UNIT (F SERIES) Installation Manual English Chilled Water Fan Coil Unit MODELS FWC02FD FWC03FD FWC04FD FWC05FD FWC06FD FWC08FD FWC10FD IM-CCFWD-0915(1)-DAIKIN Part Number.: R08019044145A...
-
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS Indoor Unit: Ceiling Concealed Fan Coil Unit F Series All dimensions are in mm LEFT PIPING All dimensions are in mm RIGHT PIPING Dimension Model FWC02/03FD FWC04/05FD FWC06FD 1060 FWC08FD 1390 1246 1207 1210 1271 FWC10FD 1600... -
Page 4: Safety Precautions
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation for the air conditioner unit. Special adjustment may be necessary to suit local requirement. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. -
Page 5: Installation Of The Indoor Unit
INSTALLATION OF THE INDOOR UNIT The indoor unit must be installed such that there is no short Ceiling Concealed Mounting circuit of the cool discharge. Respect the installation clearance. • Use the hanger supplied with the unit. Do not put the indoor unit where there is direct sunlight on •... -
Page 6: Important Notice
IMPORTANT NOTICE CORK TAPE FULLY INSTALLED INSULATION THROUGH OUT CHILLED WATER PIPING WATER PIPING CONNECTION • The indoor unit is equipped with water outlet and inlet connection. There is an air-vent that is fitted along with the connection for air purging. •... -
Page 7: Electrical Wiring Connection
ELECTRICAL WIRING CONNECTION FWC02/03/04/05/06/08/10FD FCU 1 FCU 2 FCU 3 220-240V/~/50Hz or 220-240V/~/50Hz or 220-240V/~/50Hz or 208-230V/~/60Hz 208-230V/~/60Hz 208-230V/~/60Hz Fan Low Chiller There must be an all pole Fan Medium Fan High disconnection in the supply mains Neutral with a contact separation of at Fan Speed Controller least 3mm. -
Page 8: Operating Range
• All wires must be firmly connected. • Make sure all the wire do not touch the refrigerant pipings, or any moving parts. • The power supply cord must be equivalent to H07RN-F which is the minimum requirement. • Make sure no external pressure is applied to the terminal connectors and wires. •... - Page 9 AIR FILTER SERVICES Remove air filter to side (Figure 1) Remove air filter to bottom (Figure 3) • Remove side air filter cover. (Left or Right side). • Remove bottom air filter cover. • Slide air filter out from filter rail. •...
-
Page 10: Service And Maintenance
SERVICE AND MAINTENANCE Service Parts Maintenance Procedures Period Indoor Air Filter Remove any dust adhered on the filter by using a vacuum cleaner or wash At least once every in lukewarm water (below 40°C) with neutral cleaning detergent. 2 weeks. Rinse well and dry the filter before placing it back onto the unit. - Page 12 Kita-ku, Osaka, 530-8323 Japan Tokyo offi ce: P.O.Box 18674, Jebel Ali Free Zone, Dubai-UAE Email: info@daikinmea.com JR Shinagawa East Bldg., 2-18-1, Konan, Minato-ku, Tokyo, 108-0075 Japan Web: www.daikinmea.com http://www.daikin.com/global/ Importer for Turkey Allianz Plaza-Kucukbakkalkoy Mah.Kayısdagi Cad.No:1 34750 Atasehir-ISTANBUL / TURKIYE...
