Parameter
HydroHeatingCmd Hydronic Heating command
InCoilTmp Indoor Coil Temperature
Indoor Enthalpy. Determined by space temperature and indoor air
InEnth
humidity
Internal Schedule. Result of the user-defined daily occupancy
IntSched
schedule
Low Outdoor Air Freeze Status. Indicates OAT freeze protection
LowOAFrzStat
status as active or not active
LUI Display Emergency Override. Command set from the local user
KeyEmergOv
interface
LuiEnergyHoldOff LUI Energy Hold-off. Command set from the local user interface
LUI Occupancy Manual Command. Occupancy override set from the
KeyOccManCmd
local user interface
LUI Setpoint Offset. Setpoint offset adjustment set from the local user
LuiSetptOffset
interface
LUI System Status. Current heat/cool status set from the local user
KeySysStat
interface
LWT Leaving Water Temperature
aiLWT Leaving Water Temperature sensor input
MM/DD/YYYY Date of trend point generation
Main State Machine. Function of the controller used to monitor unit
MSM
state
Network Occupancy Command. BAS-commanded occupancy
NetOccManCmd
override parameter
Multiple Alarm Compressor. Activates when one or more compressor
MultAlarmComp
alarms is generated
OADpos Outdoor Air Damper Position
OADmpr Outdoor Air Damper position analog output
Network Outdoor Air Damper Input. OAD position configured for
NetOADIn
client/server control strategy
Outdoor Air Damper Automatic Position. Maximum value of the OAD
OADAutoPos
setpoint and free cooling calculation
OADLowTmpStat Outdoor Air Damper Low Temperature Status
Network Input Outdoor Air Damper Minimum Position. BAS-
niOADMinPos commanded outdoor air damper position; overrides local control if
configured
Outdoor Air Damper Minimum Position. Minimum OAD position for
OADMinPos span fan operating at high speed, or at any speed if CO
enabled.
OADPosCO2 Outdoor Air Damper Position for CO
OADPosFreeCl Outdoor Air Damper Position for Free Cooling
OADPosReset Outdoor Air Damper Position for hard-wired reset
Outdoor Air Damper Position Low Speed. Minimum OAD position for
OAMinPosLowSpd
space fan operating at low speed
Outdoor Air Damper Position Medium Speed. Minimum outdoor air
OAMinPosMedSpd
damper position for space fan operating at medium speed
OAT Outdoor Air Temperature
niOAT Network Input Outdoor Air Temperature. BAS-commanded input
OccClSpt Occupied Cooling Setpoint
www.DaikinApplied.com
Description
/DCV is
2
2
45
Parameter
LonOccClSptSh Occupied Cooling Setpoint Shift from LonWorks (future use)
LonStdClSptSh Standby Cooling Setpoint Shift from LonWorks (future use)
OccHtSpt Occupied Heating Setpoint
LonOccHtSptSh Occupied Heating Setpoint Shift from LonWorks (future use)
LonStdHtSptSh Standby Heating Setpoint Shift from LonWorks (future use)
Network Occupancy Schedule. BAS-commanded occupancy
NtOccSched
schedule
Network Occupancy Sensor. Occupancy control from BAS-
NetOccSens
commanded room sensor
OutCoilTmp Outdoor Air Coil Temperature
Outdoor Enthalpy. Output based on current outdoor air temperature
OutEnth
and outdoor air humidity
niOutRH Outdoor Air Relative Humidity input
pwmECMSupplyFan ECM Supply Fan output
RAT Return Air Temperature from unit-mounted room/return air sensor
Reversing Valve Command. Current valve command to either heating
RevValveCmd
or cooling
Remote Sensor Fan Speed (auto, low, medium, high, off) determined
RSFanSpd
by sensor input
Remote Sensor System Mode. Status (auto, heat, cool) determined
RSSysMode
by sensor input
Setpoint Setpoint value
netSetpoint Network Setpoint. BAS-commanded setpoint value
SptAdj Setpoint Adjust. Temperature setpoint adjust analog input
LocSptShft Local Setpoint Shift. Setpoint adjustment from the room sensor
SptOffAdj Setpoint Offset Adjustment
NetSptOffst Network Setpoint Offset. BAS-commanded setpoint offset
Space CO Input. BAS-supplied space CO
niSpcCO2 2
effective space CO
SpcCO2Lim Space CO Setpoint
2
niSpcRH Space Relative Humidity Network Input
SpaceTmp Effective Space Temperature
SpcTmp Space Temperature from hard-wired input
niSpcTmp Space Temperature from BAS-commanded space temperature input
SpcTmpTO Space Temperature with Tenant Override input
SysStatCmd System Status Command. Unit heat/cool command
SZVavFanPI Single-Zone VAV Fan speed PI loop output
NetInAlarm Highest priority active alarm
ValveFrzProtect Valve Freeze Protection strategy
OM 1280-2 • MICROTECH UNIT CONTROLLER
Trending
Description
input used to determine
2
2
