Password Levels
The control has 4 levels of user access. Passwords are used
to grant level access. Depending on the level of access, certain
menus and parameters will be allowed to be read and written.
The "Expires After" column defines how long the password is
valid without a key press.
The following are the different levels of user access and the
password needed for each is shown in Table 5.
Table 5: Control Password Access Levels
Password Expires
Password
Level After
None – –
User 00068 15 minutes
Manager 00689 15 minutes
Technician 06897 8 hours
Note:
It is recommended that you contact the Daikin Applied Terminal Systems Technical
Response at TechResponseATS@daikinapplied.com or (315) 282-6434 for assistance if
needed before making changes to unit configuration, setpoints, or network parameters.
Menu Reference
The keypad menu eases troubleshooting and simplifies
control configurations. The user can access the most common
parameters and system status values without a PC or network
interface.
The LUI keypad display menu consists of an array of menus
and sub-menus that logically arranges the various parameters
that affect the operation of the UVC. Depending on password
level the user has the ability to change the value of parameters
where applicable.
OM 1280-2 • MICROTECH UNIT CONTROLLER
Description
Default. Limited read access. No
write access aside from password
entry.
Limited read and write access
to basic high level menus and
parameters.
Read access to all user parameters
plus additional menus and
parameters. Provides write access
to all but offsets and other purely
technical parameters.
Access to all menus and
parameters except 1) writing factory
configurations to internal memory
and 2) overriding outputs for
factory testing. Used by the Daikin
technicians in the field.
LUI Navigation
Changing Setpoints
HOME
• Press
• Use ▼ to place flashing cursor next to "
ENTER
• Press to select this submenu
• Use ▼ to place flashing cursor next to "
ENTER
• Press
• Use ▲ ▼ to place flashing cursor next to the setpoint to
be changed
ENTER
• Press
• Use ▲ ▼ to change value
ENTER
• Press to accept. Cursor will advance to allow you
to change the tenths value (after the decimal whole value)
• Use ▲ ▼ to change value
ENTER
• Press to accept. Cursor will return to all user
adjustable setpoints
Setting Fan Speed
HOME
• Press
• Use ▼ to place flashing cursor next to "
ENTER
• Press to select this submenu
• Use ▼ to place flashing cursor next to "
ENTER
• Press to select
• Use ▲ ▼ to change fan speed (
ENTER
• Press to select desired speed
Viewing Temperatures
HOME
• Press
• Use ▼ to place flashing cursor next to "
ENTER
• Press to select this submenu
• Use ▲ ▼ to view values
Setting Time
HOME
• Press
• Use ▼ to place flashing cursor next to "
ENTER
• Press to select this submenu
• Use ▼ to place flashing cursor next to "
ENTER
• Press
• Use ▲ ▼ to move flashing cursor next to the a value to
modify
ENTER
• Press
• Use ▲ ▼ to change value
ENTER
• Use to shift cursor on digit to the right
BACK
• Use to shift cursor one digit to the left
• Once value is as desired and cursor is flashing on the
furthest digit to the right, press
the value
• Repeat process as needed for other values
8
Getting Started
Set
"
Set-Setpoints
"
IndoorFan
"
KeyInFan
"
Auto, Low, Medium, High
)
Temperatures
"
Set
"
Set-Clock
"
ENTER
to accept and store
