Daikin MicroTech Operation And Maintenance page 65

Menu Name Minimum Password to Read
(Menu Index) (None, User, Manager, Technician)
NtOccHtSptSh:
NtStdHtSptSh:
IndoorFan
CurFanSpd:
FanState:
KeyInFan:
NetFanSpdCmd:
CalcFanSpd:
SZnVAVFanPI:
Compressor
NetCmpEn:
ClOATLckStat:
CmpHtOATLckSt:
CmpHtEWTLckSt:
CompOnTmr:
CompOffTmr:
PumpCmd:
CmpClAvl:
CmpHtAvl:
CmpStgCmd:
RevVlvCmd:
RevVlvStat:
CmpStartDly:
CondEcmFanOut:
DfrstSt:
LLCmpStgCmd:
MSMRevVlvCmd:
MSMCmpStgCmd:
MSMPumpCmd:
EmHtCmpStgCmd:
RandomStrtTm:
HydroHeating
HotWtr:
HydroHtAvl:
EwtHtState:
EwtFlwHtTmr:
DATLLHWPI:
HWVlvMxTout:
HydroCooling
ColdWtr:
HydroClAvl:
EwtClState:
EwtFlwClTmr:
OADamper
OADPos:
OADMinPos:
SpcCO2:
EconMode:
OADLowTmpStat:
OADCO2Pos:
OADAutoPos:
OADIndrFan:
FreeClAvl:
FreeClStrg:
FreeClEn:
OADPosReset:
OADPosFreCl:
niOADMinPos:
NetOADIn:
NetEconEn:
NetSpcCO2:
FaceBypassDamper
FBDmpr:
FB_PIOut:
www.DaikinApplied.com
Minimum Password to Write
(None, User, Manager, Technician)
"RO" if Read Only
N
N
N
N
N
N
T
T
N
N
N
N
N
N
N
N
N
T
T
N
M
N
N
T
T
T
T
T
T
N
N
M
T
T
T
N
N
M
T
N
N
N
N
M
T
T
T
M
T
M
T
T
N
N
N
N
N
T
Appendix – Local User Interface (LUI)
Help Text
RO Net Occupied heating setpoint shift.
RO Net Standby heating setpoint shift.
RO Current indoor fan speed.
RO Indoor fan running state.
U Keypad manual indoor fan override.
RO Network Fan spd cmd. Not 0 to 100 for Auto.
RO Calculated indoor fan speed.
RO Single zone VAV fan speed PI out.
RO Network compressor enable.
RO ASHP: Status of OAT Comp clg lock-out.
RO ASHP: Status of OAT comp htg lock-out.
RO WSHP: Status of EWT comp htg lock-out.
RO Seconds since compressor was turned on.
RO Seconds since compressor was turned off.
RO Pump command.
RO Specifies if comp cooling is avail.
RO Specifies if comp heating is avail.
RO Commanded comp cool stages.
RO Commanded reversing valve.
RO Reversing valve status.
T Timer after powerup before comp turn on.
RO Condenser fan output.
RO Current defrost state.
RO LowLimit/Reheat commanded comp stgs.
RO MSM commanded reversing valve.
RO MSM commanded comp stages.
RO MSM Pump command.
RO Emergency heat commanded comp stages.
T Dly after powerup before comp turn on.
RO Hot water valve position.
RO Specifies if hydronic heat is available.
RO EWT hydronic heating state.
RO Timer for EWT flow heat state machine.
RO DAT hot water lower limit PI.
RO Hot water valve maxed for 3 minutes.
RO Cold water valve position.
RO Specifies if hydronic cooling is avail.
RO EWT hydronic cooling state.
RO Timer for EWT flow cool state machine.
RO Outside air damper position.
RO Current OAD minimum position calc.
RO CO2 level in the space
RO Economizer mode.
RO OA damper low temperature status.
RO OAD position for CO2 control.
RO Min of OADMinPos and free clg calc.
RO Current OAD indoor fan calculation.
RO Specifies if free cooling is avail.
RO Free cooling strategy being used.
RO Free cooling enabled calculation.
RO Min OAD reset calculation.
RO OAD free cooling PI loop output.
RO Min OAD position override.
RO Client/Server OAD position.
RO Network economizer enable.
RO Network CO2 level in the space.
RO Face & bypass damper position.
RO Face & bypass PI loop output.
