Install Trim Plates - STC Clear View Assembly Instructions Manual

Install Trim Plates

Lay out the trim plates in a staging area.
Make sure the pieces are in the correct positions before assembling.
!
Carefully follow the order of assembly to ensure an easy installation.
Wear proper safety gear including work shoes, gloves and goggles.
13.1
Remove the six hex nuts from the hex bolts attached to
each G09A and G09B trim plate BEFORE installing.
13.2A
of side and roof panels and bolts are inserted
NOTE: Trim plates cover edges of roof and side panels.
13.2B
From inside of greenhouse, place
hex nuts onto hex bolts in trim plates
G09A and G09B and tighten securely.
13.3
www.stcny.com
VIEWS FROM INSIDE.
45 of 50
VIEWS FROM INSIDE.
Trim Plate
#G09A
#G09B
QTY
2
2
