3.4
Connectors P09, P10 and P18 CLICK into place.
26.8"
(680 mm)
!
3.5
Remove protective plastic from both sides of panels GY5, GY6 and GY15. The clear panels are designed
GY15
GY5
G06C
G06B
G02B
www.stcny.com
Connector
QTY
#G02E
1
#G02F
1
!
Remove protective plastic from EACH side of clear panels before installing.
Dispose of plastic properly. Install with outward curved side FACING DOWN.
GY6
G06A
G02A
NOTE: ALL VIEWS ARE FROM INSIDE.
G02F
Connector
QTY
#P09
1
GY15
G06C
Clear Panel
18 of 50
G02E
26.8"
(680 mm)
Connector
QTY
#P10
1
Clear Panel
QTY
#GY5
1
QTY
#P18
1
QTY
#GY6
1
#GY15
1
