Status LEDs
A.3

ARC SDP Board LEDs

Table A-3 describes the ARC SDP board status LEDs colors and the status they indicate.The following list
represents the color code for the supervision LEDs.
Green
Table A-3 ARC SDP Supervision LED State and Description
LED Color
+12 V
RESET Indicates the ARC SDP board reset status.
TEMP Indicates the FPGA temperature status.
Blinking
DONE Indicates the FPGA's status.
POWER Indicates the power monitor's status
TUNNEL0 Indicates the status of the AXI tunnel to the ARC CPU Card.
TUNNEL1 Indicates the status of the AXI tunnel to the HAPS system.
52
SolvNetPlus
DesignWare
Red
Description
Indicates the 12 V power supply is switched on.
Normal operation.
Reset is active.
FPGA temperature is OK
FPGA temperature higher than 75 °C (167 °F). Switch OFF the board.
FPGA temperature higher than 90°C (194 °F). Switch OFF the board.
FPGA configuration is complete.
FPGA configuration ongoing.
The required voltage levels are within tolerance.
The required voltage levels are not OK.
OK
Failure. Check the ARC CPU card connection to the ARC SDP board.
OK
Failure. Check the HT3 connection cable.
