PCIe IP Prototyping Kit Installation Guide
1.2.3

Setting Up PCIe Endpoint IP Prototyping Kits

This section provides instructions for setting up the PCIe Endpoint IP Prototyping Kit hardware.
■
Note Note Note Note
■
Figure 1-18 on page
PHY. The setting up sequence is described in the next steps.
1. Use the PCI Express extender cable to connect the endpoint device and the Hosting PC motherboard.
If you are using a prototyping kit with the Xilinx PHY, the PCIe extender cable is connected to the
❑
PCIE-8 paddle board.
If you are using a prototyping kit with the Synopsys PHY, the PCIe extender cable is connected
❑
directly to the Synopsys PHY.
2. Complete the following hardware power-up sequence to ensure proper inter-board communication.
a. Power up the HAPS-80 board. Connect the HAPS-80 power supply.
During the power-up sequence, the supervision LEDs (RESET, READY, ALERT, and PWR)
change color. After a successful power-up sequence, all LEDs must be green (see
section A.2).
The LED marked UDONE indicates if the FPGA is configured.
Attention
b. Power up the computer on which you are running the system. The HAPS-80 board LED1 turns
green to indicate the PCIe link connection (see
After you set up the PCIe Endpoint IP Prototyping Kit hardware components, continue to
Note Note Note Note
"Setting Up Software Environment"
5.60a
March 2020
For IPK setup using C10 or E16 PHY board, follow the next steps.
For IPK setup using E32 PHY board, follow the steps described on
28 illustrates the PCIe Endpoint IP Prototyping Kit, assembled with the Synopsys C10
If the UDONE LED does not turn green within 20 seconds, the FPGA is not properly
configured. Check the following items:
Make sure you are using the SD card containing the HAPS-80 FPGA build. For more
■
information on how to load the HAPS-80 FPGA build into the SD card, see chapter
"Loading HAPS-80 FPGA Build" in the DesignWare PCIe IP Prototyping Kit User
"Status LEDs", section A.2).
on page 33.
