AMP Research Power Step Installation Manual page 4

8
x4
Socket Cap
Screw
12
x4
M8x12 Flange Bolt
16
x2
LED Lamp
19
Rear Support Bracket
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
9
x20
Cable Tie (7")
13
x2
M8x25 Flange Bolt
17
Butt Connector
20
Front Support Bracket
–
T M
PARTS LIST AND HARDWARE IDENTIFICATION
10
x2
Cable Tie (11")
14
x2
Large Washer
x4
4/10
S P R I N T E R
11
x2
Posi-Tap
Connector
15
M8 Rivet Nut
18
Rivet Nut Tool
SPRINTER POWERSTEP DRILL TEMPLATE
Use center punch, pilot drill (1/8"),
then drill final hole size (17/32")
BEND DOWN 90 Degrees
21
Drill Template
IM75163 rev 01.02.20
TM
x6
