APPLICATION
Toyota Tundra CrewMax
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
MODEL YR
2007 - 2020
1/12
PART #
77137-01A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
1 2 3
4= Experienced
TOOLS REQUIRED
q Measuring tape
q 13 mm socket
q 10 mm socket
q Ratchet wrench and extension
q 13mm end wrench
q Wire stripper / cutter
q 3 /16" hex key wrench (allen wrench)
q
5 mm hex key wrench (allen wrench)
q
4mm hex key wrench (allen wrench)
q
Electrical tape
WARRANTY
5-Year Limited Warranty
IM77137 rev 10.10.19
