APPLICATION
Ford F150 SuperCab
Ford F150 SuperCrew
*Modifi cation required to running board assembly. See Item 1 on page 3.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST
Designed and manufactured by AMP Research
7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other US and Worldwide patents pending. Made in USA © 2010 AMP Research
5-year limited warranty. Professional installation is recommended.
www.amp-research.com
I N S T A L L A T I O N G U I D E
LENGTH
MODEL YR
*
72"'
2004-2008
79"
2004-2008
®
. Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221;
PART #
75105-01A
75105-01A
1/10
INSTALLATION TIME
3:00
hrs
SKILL LEVEL
2
3
1
4= Experienced
TOOLS REQUIRED
Safety goggles
Measuring tape
Flat blade screwdriver
Phillips head screwdriver
8 mm socket
10 mm socket
13 mm socket
13 mm end wrench
Ratchet wrench and extension
Wire crimpers
Wire stripper
Corrosion inhibiter
3/16" hex key wrench ( allen wrench)
4mm hex key wrench ( allen wrench)
Electrical tape
Weather proof caulking ( silicone
sealer )
IM75105 rev 05.17.11
4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMP Research 75105-01A
Summary of Contents for AMP Research 75105-01A
- Page 1 Designed and manufactured by AMP Research ® . Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221; 7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other US and Worldwide patents pending. Made in USA © 2010 AMP Research 5-year limited warranty. Professional installation is recommended. www.amp-research.com 1/10 IM75105 rev 05.17.11...
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 INSTALLATION GUIDE Attaching motor to linkage assembly The motors must be attached to the linkage assemblies before continuing the installation process. - Page 3 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Note: Some Applications require modifi cation. Application Cut Length Super Crew 79”...
- Page 4 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 PARTS LIST AND HARDWARE IDENTIFICATION 19-02802-90 10-00115-60 19-02849-90 19-02487-90 Socket cap screw Nylock Nut Hex Bolt Hex bolt...
- Page 5 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Find wire harness cover on the frame under the driver’s door. Remove both tree clips and remove wire cover.
- Page 6 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Locate mounting points; fi rst and last set of holes on the inner sill. Motor Linkage mounts toward the rear of the truck, with the exception of the passenger side of SuperCab.
- Page 7 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Route longer leg of harness across front and Connect red and black power down under driver side.
- Page 8 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Locate the appropriate signal wires as noted Remove rear door step plate and open wire below.
- Page 9 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 Route wire harness towards rear of vehicle On each side of the vehicle measure from the inside body support gussets.
- Page 10 Check that all doors activate the Power Step and the LED Lights work when doors open and close. Reinstall any remaining trim panels. Correct operation of Lights: All four lamps will illuminate upon opening any door of vehicle. Lamps will stay on until restowing of both Power Steps or until 5 minutes has expired with the doors open.
- Page 11 AMP RESEARCH LIMITED WARR ANT Y AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
