AMP Research Power Step 77121-01A Installation Manual

Jeep wrangler jk 2dr 2007-2018
Hide thumbs

Advertisement

Quick Links

Download this manual
APPLICATION
Jeep Wrangler JK 2Dr
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
2007-2018
1/11
AMP Part #
77121-01A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
1 2 3
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q 10 mm socket
q 13 mm socket
q 1/2" socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q
3 /16" hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
q
WARRANTY
5-Year Limited Warranty
IM77121 rev 5.1.19
