I N S T A L L A T I O N G U I D E
LENGTH
1/10
MODEL YR
2001-2003
(2004 Heritage)
INSTALLATION TIME
3:00
SKILL LEVEL
1 2 3
4= Experienced
TOOLS REQUIRED
Safety goggles
Measuring tape
Flat blade screwdriver
Phillips head screwdriver
Right angle drill
1/8" drill bit
21/64" drill bit
13mm socket
10 mm socket
8 mm socket
Ratchet wrench and extension
13mm end wrench
Wire crimpers
Wire stripper / cutter
Vise grip pliers
Corrosion inhibiter
3/16" hex key wrench ( allen
wrench )
5mm hex key wrench ( allen
wrench )
4mm hex key wrench ( allen
wrench )
Electrical tape
Weather proof caulking ( silicone
sealer )
IM2996 rev 11.27.06
PART #
10-02996-13
hrs
4
Advertisement
Related Manuals for AMP Research Power Step 10-02996-13
Summary of Contents for AMP Research Power Step 10-02996-13
- Page 1 TECH SUPPORT 1-888-983-2206 (Press 5 for Customer Service) Monday - Friday, 8:00 AM - 5:00 PM PST Designed and manufactured by AMP Research. Patent 6,830,257 / 6,641,158 / 6,834,875 / 6,938,909 / 6,942,233 / 7,007,961 Other US and worldwide Designed and manufactured by AMP Research. Patent 6,830,257 / 6,641,158 / 6,834,875 / 6,938,909 / 6,942,233 / 7,007,961 Other US and worldwide patents pending.
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W INSTALLATION GUIDE Attaching motor to linkage assembly The motors need to be installed before continuing with the rest of the Power Step install. - Page 3 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W (A) 19-03225-11 End cap left (x1) (B) 19-03225-12 End cap right (x1) (C) 19-02663-90 T-nut insert (x2) (D) 19-03236-90 Socket cap screw (x2)
- Page 4 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W PARTS LIST AND HARDWARE IDENTIFICATION Rear Bracket Front Bracket 16-03166-90...
- Page 5 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W Install U-Nut. Drilling Forward Mounting Holes: Install U-Nut.
- Page 6 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W Line up T-nuts of step extrusion and insert 1/4-20 The rearward edge of the board should be bolts.
- Page 7 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W Remove the front radiator shrowd to access clear Route the long harness end and power hook-up routing for Power Step wire harness.
- Page 8 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W Remove driver side step plate and kick panel. Of the Locate harness bundle under driver sill plate, open three connectors to the left of the parking brake pedal, bundle and find Black with Light Blue stripe wire.
- Page 9 A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W Under passenger front kick panel locate bundle that Connect purple trigger wire to Double Diode Harness.
-
Page 10: Limited Warranty
A M P R E S E A R C H P O W E R S T E P – F O R D F 1 5 0 S U P E R C R E W LIMITED WARRANTY AMP RESEARCH warrants product to be free from defects in material and workmanship, for terms specified below, provided there has been normal use and proper maintenance. This warranty applies to the original pur- chaser only.
