APPLICATION
Dodge Ram Regular Cab * 1500
Dodge Ram Quad Cab *
Dodge Ram Crew Cab
Dodge Ram Regular Cab *
Dodge Ram Crew Cab
Dodge Ram Mega Cab
*Modification required to running board assembly. See Item 1 on page 3.
NOTE: EXCLUDES CHASSIS CAB MODELS WITH DIESEL ENGINES.
NOTE: Wiring on the 2013-2018 models (1500/2500/3500)
and 2019 Classic, has changed. See Page 11 for details.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one OR MORE of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,413,204; 7,398,985; 7,584,975; 7,566,064; 7,487,986; 8,157,277;
8,408,571; 9,302,626; 9,561,751; 10,053,017; CA2463717 ©2012 AMP Research. All rights reserved. Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
®
MODEL YR
2009 - 2018 (2019 Classic)
1500
2009 - 2018 (2019 Classic)
1500
2009 - 2018 (2019 Classic)
2500/3500
2010 - 2018
2500/3500
2010 - 2018
2500/3500
2010 - 2018
1/16
TM
PART #
75138-01A
REV B
75138-01A
REV B
75138-01A
REV B
75138-01A
REV B
75138-01A
REV B
75138-01A
REV B
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
2
3
1
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q 13mm wrench
q 19mm wrench
q 13mm socket
q 10mm socket
q Ratchet wrench and extension
q Wire stripper / cutter
q 3/16" hex key ( allen wrench )
q 4mm hex key ( allen wrench )
q Rivet Tool
q 1/8", 9/32" and 3/16" Drill Bit
q T27 torx Bit
q Center Punch
q Anti Corrosion Paint
q Electrical tape
WARRANTY
5-Year Limited Warranty
IM75138 rev 03.02.22
4
Advertisement
Related Manuals for AMP Research Power Step 75138-01A
Summary of Contents for AMP Research Power Step 75138-01A
- Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one OR MORE of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,413,204; 7,398,985; 7,584,975; 7,566,064; 7,487,986; 8,157,277;...
-
Page 2: Exploded View
A M P R E S E A R C H P O W E R S T E P – D O D G E R A M INSTALLATION GUIDE Motor to linkage assembly NOTE: The motors will be attached on step 45 (page 14). EXPLODED VIEW •... - Page 3 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M PARTS LIST AND HARDWARE Note: Some Applications require modification IDENTIFICATION Application Cut Length Crew Cab, Mega Cab 79”...
- Page 4 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M PARTS LIST AND HARDWARE IDENTIFICATION Rivet Nut Rivet Nut Tool Wire Harness M8 Hex bolt Controller STA Blind Rivet...
- Page 5 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M NOTE: 1500 RAM Only! Powerstep installations require additional steps and come with the required additional hardware. Please read and carefully follow the instructions in Step 1 for your vehicle model.
- Page 6 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M HARDWARE MOUNTING OVERVIEW (passenger side shown) Locate forward most and rearward most mounting provisions on inner sill of truck.
- Page 7 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M With Rivet Nut Tool held in place with 19 mm wrench, Once rivet nuts are in place use a screwdriver to tighten Hex Bolt until Rivet Nut deforms and secures push back tab in hole to avoid interference with...
- Page 8 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M With linkage in position insert Hex bolts into rivet nut Linkage Installation: On rear linkages thread front locations.
- Page 9 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M If crash bracket is not present use supplied spacer in place of bracket. Spacer can be inserted after linkage is up into position.
- Page 10 Install boards: Slide mounting T-Nut of board into position and attach to linkages. Shift board forward as much as possible for proper clearance. The end of board/end cap will nest into linkage With boards in extended position step on lower mount 1/2” when positioned correctly. boards to seat linkages.
- Page 11 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M Connect power leads from Controller, Red to Remove fuse from Power Step Wire Harness. positive battery terminal and Black to the vehicle body ground as shown.
- Page 12 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M Remove panel below steering column to gain access To gain access to white connector panel against to trigger wires.
- Page 13 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M Steps 38-43 are for 2009-2012 RAM 1500 and 2010-2012 RAM 2500/3500. Route the trigger wires of Power Step Harness (Purple wires) down toward the fuse box located in front of the battery.
- Page 14 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M Route the two Wire Harness legs down over the With Posi-Taps securely in place, carefully replace connector and drop wire bundles and fuse box wheel wells toward Motor Linkages, long leg back into place.
- Page 15 A M P R E S E A R C H P O W E R S T E P – D O D G E R A M On each side of the vehicle measure from the front Drill a 9/32” hole through the pinch weld at marked edge of door line on the pinch weld to the specified locations.
-
Page 16: Final System Check
A M P R E S E A R C H P O W E R S T E P – D O D G E R A M With linkage resting square on the hex bolts Using a Using a Rivet Gun install rivets. 3/16”... - Page 17 • Registration helps us keep you up to date on product information and offers To view other Amp Research products that may be offered for your vehicle. Please visit: www.amp-research.com Rev 01.05.21...
- Page 18 5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
