APPLICATION
Ford Super Duty - Crew Cab 2008-2016
Note: The application works only on the Crew Cab model Vehicles.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one OR MORE of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,413,204; 7,398,985; 7,584,975; 7,566,064; 7,487,986; 8,157,277;
8,408,571; 9,302,626; 9,561,751; 10,053,017; CA2463717 ©2012 AMP Research. All rights reserved. Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
®
TM
1/11
AMP Part #
77134-01A
INSTALLATION TIME
3-5 Hours
Professional installation recommended
SKILL LEVEL
2
3
1
4= Experienced
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q 10 mm socket
q 13 mm socket
q 1/2" socket
q Ratchet wrench and extension
q Wire crimpers
q Wire stripper / cutter
q 3 /16" hex key wrench (allen wrench)
q 4mm hex key wrench (allen wrench)
q Electrical tape
q Weather proof caulking (silicone sealer)
q Silicone spray
WARRANTY
5-Year Limited Warranty
IM77134 rev 12.18.20
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Step XL 77134-01A and is the answer not in the manual?

Questions and answers

Related Manuals for AMP Research Power Step XL 77134-01A

Summary of Contents for AMP Research Power Step XL 77134-01A

  • Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one OR MORE of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,413,204; 7,398,985; 7,584,975; 7,566,064; 7,487,986; 8,157,277;...

  • Page 2: Exploded View

    A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y INSTALLATION GUIDE Attaching motor to Linkage assembly. EXPLODED VIEW •...
  • Page 3 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y (A) End cap left (x1) (B) End cap right (x1) (C) T-nut insert (x2) (D) Socket cap screw (x2) (E) End cap wedge right (x1)
  • Page 4 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y M6 Flange Bolt 5/16 Flange Bolt M10 washer M10 Flange Nut M5 Washer...

  • Page 5: Idler Assembly

    A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Insert 7 Carriage bolts (17) into slot on rail (4). Insert from either end of rail. Add 2 Light Brackets (25) on the 3rd and 5th bolt.
  • Page 6 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Install provided spacer (19) and M6 bolt (14) into Thread supplied bolts 2x (8) into Front Drive Linkage.
  • Page 7 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Start from rear of vehicle tighten brackets to the body of the vehicle.
  • Page 8 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Connect power and ground for controller to battery, Red to positive and Black to the negative lead. Route harness legs down over wheel wells toward motor linkages, long leg across front and over to driver side.
  • Page 9 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Connect harness to motor. Secure harness with tie wraps.
  • Page 10 A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Wire OBD II connector with Posi-Splice and plug into port. OBD II Connector located below steering column.

  • Page 11: Final System Check

    A M P R E S E A R C H P O W E R S T E P – F O R D S U P E R D U T Y Reinstall fuse.Check that all doors activate the Power Step and the LED Lights work when doors open and close.
  • Page 12 • Registration helps us keep you up to date on product information and offers To view other Amp Research products that may be offered for your vehicle. Please visit: www.amp-research.com Rev 01.05.21...

  • Page 13: Year Limited Warranty

    5-YEAR LIMITED WARRANTY AMP RESEARCH warrants this product to be free from defects in material and workmanship for FIVE (5) YEARS FROM DATE OF PURCHASE, provided there has been normal use and proper maintenance. This warranty applies to the original purchaser only.
