3.5 Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector Description
CN1 LVDS Connector - Top Side
CN2 2 x CAN 10P Internal Connector - Top Side
CN3 10P x 2 RS232 Internal Connector - Top Side
CN4 20P GPIO I2C SPI Male Connector - Top Side
CN5 LVDS Power, Backlight Connector - Top Side
CN6 CSI 44 Pin Connector - Top Side
CN7 CSI 30 Pin Connector - Top Side
CN8 SMARC 314P Connector - Top Side
CN9 USB 2.0 Internal Connector -Top Side
CN11 Upside HDMI Connector - I/O Side
CN12A RS232 DB9 Connector - I/O Side
CN12B RS232 DB9 Connector - I/O Side
CN13 USB 3.0 Double Deck -I/O Side
CN14 RJ45 Connector - I/O Side
CN15 USB OTG - I/O Side
CN17 Barrel Power Connector (CN21 Colay) -I/O Side
J1 Audio Line Out - I/O Side
SCN1 SD Connector - Bottom Side
SCN2 Mini PCIe Full Size Connector - Bottom Side
SCN3 Mini PCIe Half Size Connector - Bottom Side
SCN4 SIM Card Connector - Bottom Side
SW3 Power ON/OFF Switch - Top -Side
SW4 Power Reset Switch - Top Side
