AXIOMTEK SCM180 Hardware User Manual page 27

SCM180 & SCB180 Freescale i.MX8M ARM-based System-on-Module
Pin Signal
P137 SER2_RX
P138 SER2_RTS#
P139 SER2_CTS#
P140 SER3_TX
P141 SER3_RX
P142 GND
P143 CAN0_TX
P144 CAN0_RX
P145 CAN1_TX
P146 CAN1_RX
P147 VDD_IN
P148 VDD_IN
P149 VDD_IN
P150 VDD_IN
P151 VDD_IN
P152 VDD_IN
P153 VDD_IN
P154 VDD_IN
P155 VDD_IN
P156 VDD_IN
SCB180 Baseboard
Pin Signal
S137 LVDS0_3+ / eDP0_TX3+ / DSI0_D3+
S138 LVDS0_3- / eDP0_TX3- / DSI0_D3-
S139 I2C_LCD_CK
S140 I2C_LCD_DAT
S141 LCD0_BKLT_PWM
S142 RSVD
S143 GND
S144 N.C
S145 WDT_TIME_OUT#
S146 PCIE_WAKE#
S147 VDD_RTC
S148 LID#
S149 SLEEP#
S150 VIN_PWR_BAD#
S151 CHARGING#
S152 CHARGER_PRSNT#
S153 CARRIER_STBY#
S154 CARRIER_PWR_ON
S155 FORCE_RECOV#
S156 BATLOW#
S157 TEST#
S158 GND
