SCM180 & SCB180 Freescale i.MX8M ARM-based System-on-Module
Pin Signal
P41 SDIO_D2
P42 SDIO_D3
P43 SPI0_CS0#
P44 SPI0_CK
P45 SPI0_DIN
P46 SPI0_DO
P47 GND
P48 N.C
P49 N.C
P50 GND
P51 N.C
P52 N.C
P53 GND
P54 ESPI_CS0#
P55 ESPI_CS1#
P56 ESPI_CK
P57 ESPI_IO_0
P58 ESPI_IO_1
P59 GND
P60 USB0+
P61 USB0-
P62 USB0_EN_OC#
P63 USB0_VBUS_DET
P64 USB0_OTG_ID
P65 USB1+
P66 USB1-
P67 USB1_EN_OC#
P68 GND
P69 USB2+
P70 USB2-
P71 USB2_EN_OC#
P72 N.C
P73 N.C
P74 USB3_EN_OC#
P75 PCIE_A_RST#
P76 N.C
P77 N.C
P78 N.C
P79 GND
P80 N.C
P81 N.C
P82 GND
P83 PCIE_A_REFCK+
P84 PCIE_A_REFCK-
P85 GND
P86 PCIE_A_RX+
P87 PCIE_A_RX-
P88 GND
P89 PCIE_A_TX+
SCB180 Baseboard
Pin Signal
S41 I2S0_SDIN
S42 I2S0_CK
S43 N.C
S44 N.C
S45 RSVD
S46 RSVD
S47 GND
S48 I2C_GP_CK
S49 I2C_GP_DAT
S50 N.C
S51 N.C
S52 N.C
S53 N.C
S54 N.C
S55 N.C
S56 ESPI_IO_2
S57 ESPI_IO_3
S58 N.C
S59 N.C
S60 N.C
S61 GND
S62 USB3_SSTX+
S63 USB3_SSTX-
S64 GND
S65 USB3_SSRX+
S66 USB3_SSRX-
S67 GND
S68 USB3+
S69 USB3-
S70 GND
S71 USB2_SSTX+
S72 USB2_SSTX-
S73 GND
S74 USB2_SSRX+
S75 USB2_SSRX-
S76 PCIE_B_RST#
S77 N.C
S78 N.C
S79 N.C
S80 GND
S81 N.C
S82 N.C
S83 GND
S84 PCIE_B_REFCK+
S85 PCIE_B_REFCK-
S86 GND
S87 PCIE_B_RX+
S88 PCIE_B_RX-
S89 GND
