INVT Goodrive100-PV Series Operation Manual page 70

Goodrive100-PV Series Solar Pumping VFD
Model
GD100-2R2G-2-PV
GD100-7R5G-4-PV
GD100-004G-2-PV
GD100-011G-4-PV
GD100-5R5G-2-PV
GD100-015G-4-PV
GD100-7R5G-2-PV
GD100-018G-4-PV
GD100-022G-4-PV
GD100-030G-4-PV
GD100-037G-4-PV
GD100-045G-4-PV
GD100-055G-4-PV
GD100-075G-4-PV
GD100-090G-4-PV
GD100-110G-4-PV
GD100-132G-4-PV
GD100-160G-4-PV
GD100-185G-4-PV
GD100-200G-4-PV
Note:
 For the cable selection for model IP54, see the cables applicable to the models with the
same power as model IP54 in this table.
 It is appropriate to use the recommended cable size under 40° C and rated current. The
wiring distance should be no more than 100m.
 If the control cable and power cable must cross, the angle between them must be 90° .
 If the inside of the VFD is moist, the insulation resistance will decrease. If there is moisture
in the VFD, dry up the VFD and measure the humidity again.
Recommended cable size
2
(mm )
(+)/(-), R/S/T, U/V/W
2.5
4
4
6
6
10
10
16
25
25
35
35
50
70
95
120
185
240
120*2P
120*2P
68
Options and use
Terminal
screw
PE
2.5 M4
4 M5
4 M5
6 M5
6 M5
10 M5
10 M5
16 M5
16 M5
16 M6
16 M6
16 M8
25 M8
35 M8
50 M12
70 M12
95 M12
95 M12
150 M12
150 M12
Tightening
torque
(Nm)
1.2–1.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
2–2.5
4–6
4–6
10
10
10
31–40
31–40
31–40
31–40
31–40
31–40
