Goodrive100-PV Series Solar Pumping VFD
Function
code
Mutual inductance
P02.09
of asynchronous
Non-load current
P02.10
of asynchronous
P04 Group SVPWM control
P04.00 V/F curve setting
Name Detailed illustration of parameters
0.1–6553.5mH
motor
0.1–6553.5A
motor
These function codes define the V/F curve
of GD100-PV series motor 1 to meet the
need of different loads.
0: Straight line V/F curve; applying to the
constant torque load
1: Multi-dots V/F curve
2: Torque-stepdown characteristic curve
(1.3 order)
3: Torque-stepdown characteristic curve
(1.7 order)
4: Torque-stepdown characteristic curve
(2.0 order)
Curves 2–4 apply to the torque loads such
as fans and water pumps. Users can
adjust according to the features of the
loads to get the best performance.
5: Customized V/F(V/F separation); in this
mode, V can be separated from f and f
can be adjusted through the frequency
given channel set by P00.06 or the
voltage given channel set by P04.27 to
features.
Note: Users
modify the parameters
freely.
29
Function parameters
Default Modify
Depend
cannot
on model
Depend
on model
4
○
○
◎
