Goodrive100-PV Series Solar Pumping VFD
Function
code
S1 terminals
P05.01
function selection
S2 terminals
P05.02
function selection
S3 terminals
P05.03
function selection
S4 terminals
P05.04
function selection
S5 terminals
P05.05
function selection
HDI terminals
P05.09
function selection
Name Detailed illustration of parameters
1: HDI switch input
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and
A setting
15: Shift between combination setting and
B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
33
Function parameters
Default Modify
42
◎
43
◎
44
◎
45
◎
1
46
◎
