INVT Goodrive100-PV Series Operation Manual page 14

Goodrive100-PV Series Solar Pumping VFD
U1 and V1 are the common terminals of the windings. Connect them to the output terminal W
of the solar pumping VFD. Connect U2 to the output terminal U of the VFD. Connect V2 to the
output terminal V of the VFD. (Note: Use the screws equipped with the VFD.) Connect S4 of
the VFD to COM in short circuited manner.
3.2.2 Terminals of control circuit
Category
Power supply
Digital input
L
C1
U2
L1
V2
U1
L2
V1
N
Functions of control terminals
Terminal
Terminal name
symbol
24V 24V power supply
COM Common terminal
Forced switch to
S1
power frequency
S2 Full-water alarm
S3
K
C2 U2
L1
U1
Empty-water
alarm
12
Installation guidelines
U
V
V2
L2
V1
W
Terminal function
It provides the
24V±10% and
current of 200mA.
It functions as the working
power supply of digital input
and output or
connects to the sensor power
supply.
Terminal feature parameters:
1. Internal impedance: 3.3kΩ
2. Acceptable voltage input:
12–24V
3. Maximum input frequency:
1kHz
S1: Forcible switch to power
frequency (Switching-on
indicates switching to power
power of
maximum
externally
