Xenus
POWER, REGEN. & BRAKE CONNECTIONS
DANGER: HIGH VOLTAGE
CIRCUITS ON J1, J2, J3, J4
ARE CONNECTED TO
MAINS POWER
BRAKE
A
BRAKE
B
+
+24 Vdc
0.5 Adc
-
24V Power Supply
Required for
Drive Operation
Frame Grounding Tab
Notes:
1) Shielded cables required for CE are shown in the diagram.
2) Line filter required for CE
3) In the end product installation, a UL RC (Recognized Component) SPD (Surge Protective Device) type 1CA, 2CA, 3CA
or a UL Listed (VZCA) SPD type 1, 2, or 3 rated 2500 V, with a minimum SCCR of 5 kA, 240 Vac, and surge voltage
monitoring needs to be provided. The purpose of the SPD is to establish an over-voltage CAT II environment.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Web:
PLUS
2-Axis EtherCAT
Xenus Plus 2-Axis
J1
REGEN+
5 +24V
4 +24V
REGEN-
J2
3 BRAKE A
J5
BRAKE B
2
1 24V RTN
Frame Ground
Keep the chassis grounding
connections short for best
shielding performance
http://www.copleycontrols.com
800-1782
SPD = Surge Protection Device
L3
4
3
L2
2
L1
1
Earth
1
*
Fuse
2
*
Fuse
3
Tel: 781-828-8090
RoHS
SPD
3Ø
Fuse
L3
1Ø
N L2
H
L1
AC MAINS:
100~240 Vac
1Ø or 3Ø
47~63 Hz
