Copley Controls Xenus PLUS Manual page 18

Xenus
INPUT CONNECTIONS FOR AXIS A
CME2 SCREEN FOR INPUTS [IN1~IN10]
INPUT DATA
Input Pin R1
IN1 J12-7
10k
IN2 J12-8
IN3 J12-9
10k
IN4 J12-10
IN5 J12-11
IN6 J10-2
IN7 J10-3
IN8 J10-4 Opto
IN9 J10-5
ICOM1 J10-6
IN10 J11-7 4.99k
HI/LO DEFINITIONS: INPUTS
Input State Condition
HI Vin >= 2.5 Vdc
IN1,10
LO Vin <= 1.3 Vdc
HI Vin > 2.5 Vdc
IN2~5
LO Vin < 2.5 Vdc
HI Input diode ON
IN6~9
LO Input diode OFF
IN6~9 are optically isolated and work from positive
or negative input voltages. When voltage is applied
to an input and current flows through the input
diode of the opto-coupler the diode condition is
ON. When no voltage is applied to an input and no
current flows through the input diode it is OFF.
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Tech Support: E-mail: sales@copleycontrols.com, Web:
PLUS
[IN1]
R2 C1
10k 100p
1k 100p
+30Vmax
+24V typical
[IN2~5]
+24V
Vmax
+5V
10k 33n
INPUTS WITH
PROGRAMMABLE
PULL UP/DOWN
Input
IN1
IN2
IN3
IN4
IN5
2-Axis EtherCAT
PullUp = 5V
+5V
PullDown = 0V
74HC14
10k
[INx]
10k
100p
J12 Control
12V
+5V
10k
MAX3096
1k
[IN2,4,12,14]
100 pF
+5V
10k
1k
[IN3,5,13,15]
100 pF
MAX3096
Pin PU/PD
J12-7 1
J12-8 2
J12-9 3
J12-10
4
J12-11
Tel: 781-828-8090
http://www.copleycontrols.com
800-1782
[IN6~9]
J9
24V GND
[COMM1]
24V
+ 6
[IN6]
2
[IN7]
3
[IN8]
4
2.5V
[IN9]
5
+
+
24V
[IN10]
+5V
10k
[INx]
4.99k
33nF
Fax: 781-828-6547
Page 18 of 32
RoHS
4.7k
4.99k
5.1V
4.7k
4.99k
5.1V
4.7k
4.99k
5.1V
4.7k
4.99k
5.1V
74HC14
