Installation manual
Drives and control units for roller
shutters and sun protection systems

Advertisement

Table of Contents
loading

Related Manuals for Becker M

Summary of Contents for Becker M

  • Page 1 Installation manual Drives and control units for roller shutters and sun protection systems...
  • Page 2 Becker control units. This manual is intended for technicians who have been trained by Becker-Antriebe GmbH. It is essential that you follow the safety instructions for the installation and commissioning of tubular drives and control units on pages 160-161 at the end of the installation manual.

  • Page 3: Table Of Contents

    Roller shutter drive types ....4 E03 drives ........30 Identification of the drive type ..6 E14 drives ........36 M (M04) drives ....... 8 PR+ drives ........40 M17 drives ........12 E01 drives ........44 PicoR+ drives ....... 14 PRF+ drives ........

  • Page 4: Roller Shutter Drive Types

    General Roller shutter drive types Type M: Type R(+): Drive with mechanical (1997-2009) limit switching Drive with electronic limit switching and sensitive obstruction detection Type Pico R+: Type RF(+): (1999-2007) (2000-2002) Drive with electronic limit Drive with radio receiver switching for the mini...
  • Page 5 Type RO(+): Type B01: (from 2010) (from 2012) Drive with electronic limit Drive with B-Tronic radio switching and sensitive receiver (868.3 MHz), obstruction detection point to point program- ming and sensitive obstruction detection Type C01: Type E01: (from 2013) (from 2014) Drive with Centronic radio Drive with electronic receiver (868.3 MHz),...

  • Page 6: Identification Of The Drive Type

    If the drive produces a loud noise and the tube does not turn, the drive is a type M. Replace the program- ming unit immediately with one that is suitable for an M drive. If the drive clicks twice, an...
  • Page 7 Turn the drive roughly 3 revolutions then press the programming button again for 2 seconds (the drive clicks again to indicate that a second limit position has been set). Turn the drive roughly 1.5 revolutions in the opposite direction and carry out the deletion sequence: - Press and hold the programming button - Press and hold the button...

  • Page 8: M (M04) Drives

    M (M04) drives Type plate Type designation: e.g. R 8/17 C M Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 8/17 Rated torque/output speed Pluggable connecting cable Mechanical limit switching Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 9 Information Before installation, make sure that the drive adapter safety catch has engaged (is screwed tight). Mark the position of the drive adapter on the tube and drill a 4-mm hole at this point. Secure the drive adapter against axial displacement in the tube using a screw or a rivet.
  • Page 10 M (M04) drives Setting the limit positions 1. Setting the lower limit position After the tube is installed, run the drive downwards until it switches off auto- matically. Using the flex- ible setting tool, turn the corresponding adjuster in the + direction (clockwise)
  • Page 11 2. Setting the upper limit position Run the roller shutter upwards until the drive switches off automatically via the limit switch for the upper limit position. Note: When delivered (from the factory), the limit switch range is pre- set to 2 revolutions in the UP and DOWN directions.

  • Page 12: M17 Drives

    M17 drives Type plate Type designation: e.g. R4-M17 Size of drive (tube diameter) R - 45 mm Rated torque (4 Nm) Mechanical limit switching Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off Serial number: e.g.
  • Page 13 Information M17 drives with mechanical limit switching detect both limit positions automatically. In order for the drive to detect the upper limit position, a defined stop must be present (angled strip or mechanical stop). To detect the lower limit position, fixed shaft connectors must be installed.

  • Page 14: Picor+ Drives

    PicoR+ drives Type plate Type designation: e.g. P 9/16 R+ Size of drive (tube diameter) P - 35 mm 9/16 Rated torque/output speed Electronic limit switching for roller shutters Suitable for anti-lifting device Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 15 Information PicoR+ drives with electronic limit switching detect and program the upper limit position automatically. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop). The springs are attached to the mini tube using tube clamps.
  • Page 16 PicoR+ drives Programming the limit positions 1. Programming the upper limit position First, run the roller shutter towards the upper limit position until the drive switches off automatically. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).
  • Page 17 3. Programming the travelling distance Run the roller shutter towards the upper limit position again, without stopping, until the drive switches off automatically. This time, the drive learns the distance between the limit positions and auto- matically concludes the programming phase.

  • Page 18: R(+) Drives

    R(+) drives Type plate Type designation: e.g. R 8/17 R+ Size of drive (tube diameter) R - 45 mm 8/17 Rated torque/output speed Electronic limit switching for roller shutters Suitable for anti-lifting device Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 19 Information R(+) drives with electronic limit switching detect and program both limit positions automatically. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop). Installation with springs of type R No more than one roller shutter slat should jut out over the intake guide.
  • Page 20 R(+) drives Programming the limit position when installing with springs 1. Programming the upper limit position First, run the roller shutter towards the upper limit position until the drive switches off automatically. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).
  • Page 21 Programming the limit position when installing with anti-lifting devices 1. Programming the upper limit position First, run the roller shutter towards the upper limit position until the drive switches off automatically. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).

  • Page 22: Ro+ (E02) Drives

    RO+ (E02) drives Type plate Type designation: e.g. R 8/17RO+ Size of drive (tube diameter) R - 45 mm 8/17 Rated torque/output speed Electronic limit switching for roller shutters Sensitive obstacle detection Suitable for anti-lifting device Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 23 Information RO+ (E02) drives with electronic limit switching detect and program both limit positions automatically. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop). Installation with springs No more than one roller shutter slat should jut out over the intake guide.
  • Page 24 RO+ (E02) drives Setting the limit positions using the programming unit 1. Programming the upper limit position First, run the roller shutter towards the upper limit position until the drive switches off automatically. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).
  • Page 25 3. Deleting the limit positions using the programming unit - Press and hold the programming button - Press and hold the button - Release the programming button - Press the programming button again until the drive clicks twice. 4. Deleting the limit positions using any operator control Run the drive for 6 seconds in the UP or DOWN direction.

  • Page 26: Rp(+) Drives

    RP(+) drives Type plate Type designation: e.g. R 8/17RP+ Size of drive (tube diameter) R - 45 mm 8/17 Rated torque/output speed Point to point programming pos- sible Electronic limit switching for roller shutters Suitable for anti-lifting device Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 27 Information RP(+) drives with electronic limit switching detect and program both limit positions automatically. If no stops exist, limit switch points are programmed. In order for the drive to detect the upper limit position automatically, a defined stop must be present (angled strip or mechanical stop).
  • Page 28 1x click position Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. To upper stop Run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 29 3. Deleting the limit positions using the programming unit - Press and hold the programming button - Press and hold the button - Release the programming button - Press the programming button again until the drive clicks twice. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).

  • Page 30: E03 Drives

    E03 drives Type plate Type designation: e.g. R8-E03 Size of drive (tube diameter) P - 35 mm R - 45 mm Rated torque Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off. Serial number: e.g.
  • Page 31 Information E03 drives with electronic limit switching detect and program both limit positions automatically. If no stops exist, limit switch points are programmed. In order for the drive to detect the upper limit position automatically, a defined stop must be present (angled strip or mechanical stop).
  • Page 32 1x click position Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. To upper stop Run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 33 3. Deleting the limit positions using the programming unit - Press and hold the programming button - Press and hold the button - Release the programming button - Press the programming button again until the drive clicks twice. Note: For safety reasons, the drive uses less force when opening the shutter for the first time (installation run).
  • Page 34 E03 drives Setting the limit positions using the operator control 1. Setting the upper limit position using the operator control Set both switches on the drive to the programming setting ( ). To upper stop Run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 35 2. Setting the lower limit position using the operator control To lower stop Run the roller shutter towards the lower stop until the drive stops automatically. To lower point 1x click roller shutter lower limit position . Now move the roller shutter up briefly twice, then back down until the drive stops automatically and clicks once...

  • Page 36: E14 Drives

    E14 drives Type plate Type designation: e.g. R8-17-E14 Size of drive (tube diameter) R - 45 mm 8-17 Rated torque/output speed Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off. Serial number: e.g.
  • Page 37 Information E14 drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 38 1x click 1x click using the programming unit Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. To upper stop roller shutter towards the upper stop until the drive stops automatically.
  • Page 39 Setting the limit positions using the operator control 1. Setting the upper limit position 1x click using the operator control To upper stop Run the roller shutter towards the upper stop until the drive stops automatically. To upper point Run the roller shutter to the upper limit position .

  • Page 40: Pr+ Drives

    PR+ drives Type plate Type designation: e.g. R 8/17 C PR+ Size of drive (tube diameter) P - 35 mm R - 45 mm 8/17 Rated torque/output speed Pluggable connecting cable Point to point programming pos- sible Electronic limit switching for roller shutters Suitable for anti-lifting device Operating mode (short-period operation...
  • Page 41 Information PR+ drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 42 PR+ drives Setting the limit positions with the switches 1. Deleting both limit positions with the switches Set both switches to and execute a short drive command. 2. Setting the lower limit position with the switches To lower point Run the roller shutter to the desired position and switch the correspond- ing switch from to .
  • Page 43 Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. Set both switches to the programming setting ( ). To lower point Run the roller shutter to the desired...

  • Page 44: E01 Drives

    E01 drives Type plate Type designation: e.g. R8-E01 Size of drive (tube diameter) P - 35 mm R - 45 mm Rated torque Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off. Serial number: e.g.
  • Page 45 Information E01 drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the up- per limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 46 E01 drives Setting the limit positions with the switches 1. Deleting both limit positions with the switches Set both switches to and execute a short drive command. 2. Setting the upper limit position with the switches To upper stop Set both switches to and run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 47 Setting the limit positions using the operator control 1. Setting the upper limit position 1x click using the operator control Set both switches on the drive to the programming setting ( ). To upper stop Run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 48 1x click using the programming unit Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. Set both switches to the programming setting ( ). To upper stop...
  • Page 49 Note: The drive indicates the lack of a limit position by briefly starting up, stopping and then continuing (limit position status indicator). Once the limit positions have been detected correctly 3 times in succession (3 opening and closing movements), the drive definitively saves the limit positions. Activating special functions 4.

  • Page 50: Prf+ Drives

    PRF+ drives Type plate Type designation: e.g. R8/17 C PRF+ Size of drive (tube diameter) P - 35 mm R - 45 mm 8/17 Rated torque/output speed Pluggable connecting cable Point to point programming pos- sible Electronic limit switching for roller shutters Radio receiver Suitable for anti-lifting device...
  • Page 51 Information PRF+ drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the up- per limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 52 PRF+ drives Setting the limit positions 1. Programming the upper limit po- 1x click sition with the master transmitter To upper stop Run the roller shutter towards the upper stop until the drive stops automatically. To upper point Run the roller shutters to the desired upper position.
  • Page 53 Setting the intermediate positions 4. Programming the intermediate 1x click position I Run the drive to the required interme- diate position I and press the STOP and DOWN buttons until the drive clicks once. To travel to intermediate position I, press the DOWN button twice within one second (double tap) 5.

  • Page 54: Prof+ Drives

    PROF+ drives Type plate Type designation: e.g. R8/17 C PROF+ Size of drive (tube diameter) P - 35 mm R - 45 mm 8/17 Rated torque/output speed Pluggable connecting cable Point to point programming possible Electronic limit switching for roller shutters Sensitive obstacle detection Radio receiver...
  • Page 55 Information PROF+ drives with electronic limit switch- ing detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the up- per limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 56 PROF+ drives Setting the limit positions 1. Programming the upper limit po- 1x click sition with the master transmitter To upper stop Run the roller shutter towards the upper stop until the drive stops automatically. To upper point Run the roller shutters to the desired upper position.
  • Page 57 Setting the intermediate positions 4. Programming the intermediate 1x click 1x click position/ventilation position Run the drive to the required intermediate position/ventilation position and press the STOP and DOWN buttons or STOP and UP buttons until the drive clicks once. To travel to the intermediate position/ ventilation position, press the DOWN button or UP button twice within one...

  • Page 58: C01 Drives

    C01 drives Type plate Type designation: e.g. R8-C01 Size of drive (tube diameter) P - 35 mm R - 45 mm Rated torque Centronic remote control Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off. Serial number: e.g.
  • Page 59 Information C01 drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the up- per limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 60 C01 drives Setting the limit positions 1. Programming the upper limit po- 1x click sition with the master transmitter To upper stop Run the roller shutter towards the upper stop until the drive stops automatically. To upper point Run the roller shutters to the desired upper position.
  • Page 61 Setting the intermediate positions 4. Programming the intermediate position/ventilation position 1x click 1x click Run the drive to the required intermediate position/ventilation position and press the STOP and DOWN buttons or STOP and UP buttons until the drive clicks once. To travel to the intermediate position/ ventilation position, press the DOWN button or UP button twice within one...

  • Page 62: B01 Drives

    B01 drives Type plate Type designation: e.g. R8-B01 Size of drive (tube diameter) P - 35 mm R - 45 mm Rated torque B-Tronic radio drive Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off. Serial number: e.g.
  • Page 63 Information B01 drives with electronic limit switching detect and program the limit positions automatically if stops exist. If no stops exist, limit switch points are programmed. In order for the drive to detect the upper limit position correctly, a defined stop must be present (angled strip or mechanical stop).
  • Page 64 B01 drives Setting the limit positions First, put the transmitter into 1x click master mode. Press the master button under the battery compartment lid repeatedly until the drive clicks once. 1. Programming the upper limit position (in master mode) To upper stop Run the roller shutter towards the upper stop until the drive stops automatically.
  • Page 65 4. Activating the anti-freeze 3x click 1x click mechanism at the top (in master mode) Run the roller shutter towards the upper stop. Then press the program- ming button until the drive clicks once. Then press the programming button, STOP button and UP button until the drive clicks three times.

  • Page 66: Vc420-Ii Control Unit

    VC420-II control unit Commissioning Wiring Drive The external radio receiver VC420-II allows conventional drives to be converted to ra- dio drives. An additional push-button input on the VC420-II enables operation via an external UP/DOWN push-button. Connect the VC420-II as shown in the example opposite.
  • Page 67 Functions of the VC420-II Individual inputs An UP/DOWN button can be connected at the individual inputs. Press the button and keep it pressed for a time to trigger the UP/ DOWN command. Press the button briefly to trigger a stop command. Press the UP/ DOWN button briefly twice to move to the corresponding intermediate position.

  • Page 68: Vc4200B Control Unit

    Correcting the direction of rotation The direction can be reversed by swap- ping round the brown and black wires of the drive connecting cable. The direction can also be reversed using the Becker hand-held transmitter (see B01 drive type, adjusting the direction of rotation).
  • Page 69 Functions Pos. 3: ON/OFF Pos. 4: ON and Connection of light controller/ OFF after radio switch 10 min. Pos. 5: ON and The VC4200B can be operated as a OFF after 3 radio switch. The function switch must Light min. be put in the desired position before Pos.

  • Page 70: Sc431-Ii Control Unit

    SC431-II control unit Commissioning the radio-controlled light sensor SC431-II 1x click Programming the SC431-II 1. Press the programming button on the right-hand side of the master transmitter (the transmitter that was programmed first) until the receiver clicks once. Master transmitter 3.
  • Page 71 Setting the sun protection function 1. By turning threshold regulator, you can adjust the the sun threshold setting with the aid of the indicator lamp. LED green LED red LED flashes Sun protection Sun protection yellow, rotary function is function is not switch at executed executed...

  • Page 72: Drives For Sun Shading Devices

    General Drives for sun shading devices Type M: Type S(+): Drive with mechanical (1997-2003) limit switching Drive with electronic limit switching Type SF(+): Type PS(+): (2000-2003) (2000-2002) Drive with electronic Drive with electronic limit limit switching and radio switching and point to...
  • Page 73 Type E18: Type C18: (from 2015) (from 2015) Drive with Centronic radio Drive with electronic limit receiver (868.3 MHz) and switching and sensitive sensitive obstruction obstruction detection for detection for ZIP screens ZIP screens Type E12: Type C12: (from 2017) (from 2017) Drive with electronic limit Drive with Centronic radio...

  • Page 74: Identification Of The Drive Type

    M. Replace the programming unit immediately with one that is suitable for an M drive. If the drive does not react or clicks once or twice, it is an S(+), PS(+), SEB(+), SE I1, SEF I1, SF(+), PSF(+), C12 or C18 drive type.
  • Page 75 If the drive does not react, it is an SF(+) (up to 2002), PSF(+) (2003 to 2017), SEFI1 (from 2012), C18 (from 2017) or C12 (from 2017) drive type with integrated radio receiver. If the system is equipped with a locking system and the drive does not react, it is an SEF I1 SE I1...

  • Page 76: M (M04) Drives

    M (M04) drives Type plate Type designation: e.g. R 8/17 C M Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 8/17 Rated torque/output speed Pluggable connecting cable Mechanical limit switching Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 77 Information Before installation, make sure that the drive adapter safety catch has engaged (is screwed tight). Mark the position of the drive adapter on the tube and drill a 4-mm hole at this point. Secure the drive adapter against axial displacement in the tube using a screw or a rivet.
  • Page 78 M (M04) drives Setting the limit positions 1. Setting the Extend limit position After the tube is installed, move the drive in the Extend direction until it stops automatically. Using the flexible setting tool, turn the corresponding adjuster in the + direction (clockwise)
  • Page 79 Switch off the retracting mecha- nism. Using the flexible setting tool, turn the adjuster for the Extend limit position 3-10 revolutions in the - di- rection (depending on how many times the fabric is wrapped around the tube when the shading solution is extended).

  • Page 80: S(+) Drives

    S(+) drives Type plate Type designation: e.g. R 20/17 S+ Size of drive (tube diameter) R - 45 mm L - 58 mm 20/17 Rated torque/output speed Electronic limit switching for sun protection Higher closing force for cassette awnings Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 81 Information S(+) drives with electronic limit switching detect and program the Retract limit position automatically if a permanent stop exists. S drives S drives are used to operate screens, awnings and conservatory shading. S+ drives S+ drives are used to operate cassette awnings that require a higher closing torque.
  • Page 82 Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker program- ming unit. Run the shading solution to the desired position and press the pro- gramming button until the drive clicks once.
  • Page 83 3. Deleting the limit positions using the programming unit 2x click Press the programming button on the programming unit until the drive clicks twice.

  • Page 84: Ps(+) Drives

    PS(+) drives Type plate Type designation: e.g. R 30/17 C PS+ Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 30/17 Rated torque/output speed Pluggable connecting cable Point to point programmable Electronic limit switching for sun protection Higher closing force for cassette awnings...
  • Page 85 Information PS(+) drives with electronic limit switching detect and program the Retract limit position automatically if a permanent stop exists. If no stop exists, a limit switch-off point is programmed. PS drives PS drives are used to operate screens, awnings and conservatory shading.
  • Page 86 PS(+) drives Setting the limit positions with the switches 1. Deleting both limit positions with the switches Set both switches to and execute a short drive command. 2. Programming the Extend limit position Run the shading solution to the desired position and change the corresponding switch from to .
  • Page 87 Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker program- ming unit. At least one switch on the drive head must be in the position.

  • Page 88: E15 Drives

    E15 drives Type plate Type designation: e.g. R 30-17-E15 Size of drive (tube diameter) R - 45 mm L - 58 mm 30-17 Rated torque/output speed Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 89 Information Stop behaviour Increased stop behaviour with cassette awnings The E15 can be switched between increased and reduced stop behav- Reduced stop behaviour with open awnings, screens, iour. etc. Setting the limit positions The limit positions can be set in 2 different ways: .
  • Page 90 Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker program- ming unit. Run the shading solution to the desired position and press the programming button until the drive clicks once.
  • Page 91 Setting the limit positions using the operator control 1. Setting the Extend limit 1x click position using the operator control To lower point Run the shading solution to the lower limit position . Now move the shad- ing solution up briefly twice, waiting for 1 second in between movements, then back down until the drive stops automatically and clicks once...

  • Page 92: E12 Drives

    E12 drives Type plate Type designation: e.g. R30-17-E12 Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 30-17 Rated torque/output speed Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 93 Information Autoinstall The E12 can automatically detect and program the optimum maximum Extend limit position for articulat- ed-arm and cassette awnings via the Autoinstall function. Stop behaviour Increased stop behaviour with cassette awnings The E12 can be switched between increased and reduced stop behav- Reduced stop behaviour with open awnings, screens, iour.
  • Page 94 E12 drives Setting the limit positions via Autoinstall Autoinstall with articulated arm and cassette awnings Run the shading solution in the Extend direction until it passes the Extend limit position and the fabric is resting on the articulated arms Then run the shading solution without stopping in the Retract direction until it stops automati- cally at the upper stop...
  • Page 95 Setting the limit positions with the switches 1. Deleting both limit positions with the switches Set both switches to and execute a short drive command. 2. Programming the Extend limit position Run the shading solution to the desired position and change the corresponding switch from to .
  • Page 96 Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker programming unit. At least one switch on the drive head must be in the position. Run...
  • Page 97 Setting the limit positions using the operator control 1. Setting the Extend limit 1x click position using the operator control At least one switch on the drive head must be in the position. To lower point Run the shading solution to the lower limit position .
  • Page 98 E12 drives Setting the stop behaviour On delivery, the 35 diameter drive types have a reduced stop behav- iour, and the 45 diameter and 58 di- ameter drive types have an increased stop behaviour. The stop behaviour can only be changed during the first 3 runs towards the upper stop.
  • Page 99 Setting the special function fabric stretching 1. Activating the fabric stretching function Run the shading solution to the Ex- tend limit position Then press the programming button until the drive confirms by retracting and extending Then move the shading solution to the fabric stretching position press the programming button again until the drive confirms by retracting...

  • Page 100: Se-B(+) Drives

    SE-B(+) drives Type plate Type designation: e.g. R 40/17 SE-B+ Size of drive (tube diameter) R - 45 mm L - 58 mm 40/17 Rated torque/output speed Electronic limit switching for sun protection Automatic fabric stretching in the Extend limit position Higher closing force for cassette awnings Operating mode (short-period operation...
  • Page 101 Information SE-B(+) drives with electronic limit switching detect and program the Retract limit position automatically. A fixed stop must be available in the Retract limit position. An automatic reversal function in the Extend limit position ensures that the fabric is stretched. SE-B drives SE-B drives are used to operate screens, awnings and conservatory...
  • Page 102 SE-B(+) drives Setting the limit positions using the programming unit 1. Programming the Extend 1x click limit position with the programming unit Connect the wires of the tubular drive to those of the same colour in the programming unit. Run the shading solution to the de- sired position and press the pro- gramming button until the drive clicks once.
  • Page 103 3. Deleting the limit positions using the programming unit - Press and hold the programming button - Press and hold the button - Release the programming button - Press the programming button again until the drive clicks twice. If the drive is situated between the limit positions, both limit positions are deleted.

  • Page 104: Se+ K5 Mute Drives

    SE+ K5 mute drives Type plate Type designation: e.g. R40/17C SE+ K5 mute size of drive (tube diameter) R - 40 mm 40/17 Rated torque/output speed Pluggable connecting cable Electronic limit switching for sun protection Various special functions Higher closing force for cassette awnings mute Extremely quiet operation...
  • Page 105 Information SE+ K5 mute drives with electronic limit switching are characterised by their very smooth and quiet opera- tion. Sound-absorbing elements are used to achieve low noise emission. In order to detect the Retract limit position, a permanent limit stop must be present.
  • Page 106 SE+ K5 mute drives Setting the limit positions using the operator control 1. Setting the limit positions using the programming unit Auto install (only articulated-arm awnings) Run the shading solution in the Extend direction until it passes the Extend limit position and the fabric is resting on the articulat- ed arms Then run the shading solution...
  • Page 107 Setting the limit positions using the programming unit 1. Programming the limit 1x click positions Connect the wires of the tubular drive to those of the same colour in the programming unit. Run the shading solution to the desired position and press the programming button until the drive clicks once.

  • Page 108: E18 Drives

    E18 drives Type plate Type designation: e.g. R12-17-E18 Size of drive (tube diameter) P - 35 mm R - 45 mm 12-17 Rated torque/output speed Electronic limit switch Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 109 Information Obstacle detection In order to avoid uncontrolled unwinding of the shading solution, obstructions in the DOWN direction are detected (such as wind load). sensitive obstruction Drive adapter Drive adapter with detection to become active, the obstacle detection drive adapter must be fitted with obstruction detection on the drive and the shading solution must have a heavy end strip.
  • Page 110 E18 drives Setting the limit positions via Autoinstall 1. Programming the Retract limit position At least one switch on the drive head must be in the position. Run the shading solution towards the stop until the drive stops auto- matically. 2.
  • Page 111 Setting the limit positions with the switches 1. Deleting both limit positions with the switches Set both switches to and execute a short drive command. 2. Programming the Extend limit position Run the shading solution to the desired position and change the corresponding switch from to .
  • Page 112 1x click programming unit Connect the wires in the connecting cables of the drive to the wires of the same colour in the Becker program- ming unit. At least one switch on the drive head must be in the position. Run...
  • Page 113 Setting the limit positions using the operator control 1. Programming the Extend 1x click limit position using the operator control At least one switch on the drive head must be in the position. Run the shading solution to the lower limit position .
  • Page 114 E18 drives Setting the special function fabric untensioning Activating/deactivating the fabric untensioning function Run the shading solution towards the upper stop Press the programming button until the drive confirms the activa- tion or deactivation of the fabric untensioning with a short extension and retraction Sensitive obstacle detection If an obstruction is detected during...

  • Page 116: Se I1 Drives

    SE I1 drives Type plate Type designation: e.g. R 8/17 SE I1 Size of drive (tube diameter) R - 45 mm L - 58 mm 8/17 Rated torque/output speed Pluggable connecting cable Electronic limit switching for sun protection Automatic reversing in the lower limit position Programmable for different lock- ing systems...
  • Page 117 Information SE I1 drives with electronic limit switching detect and program the Retract limit position automatically. A fixed stop must be available in the Retract limit position. The shading solution is automatically locked and tightened in the Extend position. Locking principle Click Click The shading solution is extended...
  • Page 118 SE I1 drives Setting the limit positions 1. Programming the Retract limit position Connect the wires of the tubular drive to those of the same colour in the programming unit. Run the shading solution towards the upper stop until the drive stops automatically.
  • Page 119 3. Moving the shading solution into the locking mechanism Run the shading solution up into the locking mechanism until the drive switches off automatically. 4. Programming the unlocking 1x click limit position Run the shading solution down out of the locking position until the locking mechanism clicks .

  • Page 120: Psf(+) Drives

    PSF(+) drives Type plate Type designation: e.g. R30/17C PSF+ Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 30/17 Rated torque/output speed Pluggable connecting cable Point to point programmable Electronic limit switching for sun protection Radio receiver Higher closing force for cassette...
  • Page 121 Information PSF(+) drives with electronic limit switching detect and program the Retract limit position automatically if a permanent stop exists. If no stop exists, a limit switch-off point is programmed. PSF drives PSF drives are used to operate screens, awnings and conservatory shading.
  • Page 122 PSF(+) drives Setting the limit positions 1. Programming the Extend 1x click limit position with the master transmitter Run the shading solution to the Extend limit position. Then press the programming button and the EXTEND button until the drive clicks once.
  • Page 123 Setting the intermediate positions 1. Programming the 1x click intermediate position I Run the shading solution to the de- sired intermediate position press the STOP and EXTEND buttons until the drive clicks once. To travel to intermediate position I, press the EXTEND button twice with- in one second.

  • Page 124: Sef I1 Drives

    SEF I1 drives Type plate Type designation: e.g. R8/17C SEF I1 Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 8/17 Rated torque/output speed Pluggable connecting cable Electronic limit switching for sun protection Automatic reversing in the lower limit position...
  • Page 125 Information SEF I1 drives with electronic limit switching detect and program the Retract limit position automatically. A fixed stop must be available in the Retract limit position. The shading solution is automatically locked and tightened in the Extend position. Locking principle The shading solution is extended until the bolt has passed the locking point (bolt clicks).
  • Page 126 SEF I1 drives Setting the limit positions 1. Programming the Retract limit position using the master transmitter Connect the wires of the tubular drive to those of the same colour in the programming unit. Run the shading solution towards the upper stop until the drive stops automatically.
  • Page 127 3. Moving the shading solution into the locking mechanism using the master transmitter Run the shading solution up into the locking mechanism until the drive switches off automatically. 4. Programming the unlocking 1x click limit position using the master transmitter Run the shading solution down until the locking mechanism clicks Then press the programming button...

  • Page 128: C12 Drives

    C12 drives Type plate Type designation: e.g. R30-17-C12 Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 30-17 Rated torque/output speed Centronic remote control Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 129 Information Autoinstall The C12 can automatically detect and program the optimum maximum Extend limit position for articulat- ed-arm and cassette awnings via the Autoinstall function. Stop behaviour Increased stop behaviour with cassette awnings The C12 can be switched between increased and reduced stop behav- Reduced stop behaviour with open awnings, screens, iour.
  • Page 130 C12 drives Setting the stop behaviour On delivery, the 35 diameter drive types have a reduced stop behaviour, and the 45 diameter and 58 diameter drive types have an increased stop behaviour. The stop behaviour can only be changed during the first 3 runs towards the upper stop. Switching on reduced stop behaviour Move the shading solution in the...
  • Page 131 Setting the limit positions 1. Programming the Extend 1x click limit position with the master transmitter Run the shading solution to the Extend limit position. Then press the programming button and the EXTEND button until the drive clicks once. 2. Programming the Retract 1x click limit position with the master transmitter...
  • Page 132 C12 drives Setting the intermediate positions 1. Programming the 1x click intermediate position I Run the shading solution to the desired intermediate position and press the STOP and EXTEND but- tons until the drive clicks once. To travel to intermediate position I, press the EXTEND button twice with- in one second.
  • Page 133 Setting the special function fabric untensioning 1. Activating/deactivating the fabric untensioning function On delivery, the fabric untensioning function is deactivated on drive types with a diameter of 35 mm, and is ac- tivated on drive types with diameters of 45 mm and 58 mm. Run the shading solution towards the upper stop .

  • Page 134: C18 Drives

    C18 drives Type plate Type designation: e.g. R30-17-C18 Size of drive (tube diameter) P - 35 mm R - 45 mm L - 58 mm 30-17 Rated torque/output speed Centronic remote control Consecutive number Operating mode (short-period operation After 4 minutes of continuous operation, the drive must be allowed to cool off.
  • Page 135 Information Obstacle detection In order to avoid uncontrolled unwinding of the shading solution, obstructions in the DOWN direction are detected (such as wind load). For the sensitive obstruction de- Drive adapter Drive adapter with tection to become active, the drive obstacle detection adapter must be fitted with obstruc- tion detection on the drive and the...
  • Page 136 C18 drives Setting the limit positions via Autoinstall 1. Programming the Retract limit position Run the shading solution towards the stop until the drive stops auto- matically. 2. Programming the Extend limit position Travel in the Extend direction and keep the travel button pressed, until the drive moves past the Extend limit position , then moves upwards...
  • Page 137 Setting the limit positions 1. Programming the Extend 1x click limit position with the master transmitter Run the shading solution to the Extend limit position. Then press the programming button and the EXTEND button until the drive clicks once. 1x click 2.
  • Page 138 C18 drives Setting the special function fabric untensioning 1. Activating/deactivating the fabric untensioning function On delivery, the fabric untensioning function is deactivated on drive types with a diameter of 35 mm, and is ac- tivated on drive types with a diameter of 45 mm.

  • Page 140: Sws241 Control Set

    SWS241 control set Commissioning the SWS241 radio-controlled Sun-Wind-Set hand-held transmitter with sensor 1. Programming the master transmitter a. Run the shading solution to a centre position using the UP/ STOP/DOWN toggle switch. b. Press the programming button on the SWC510. The SWC510 goes into programming...
  • Page 141 Use the tool provided to turn the wind threshold regulator to the de- sired setting. The wind threshold has 11 possible settings (approx. 2m/s to 22 m/s). When slowly turning the regulator, the shading solution shifts to indi- cate the setting changes.

  • Page 142: Sws441/Sws641 Control Set

    SWS441/SWS641 control set Commissioning the SWS441/SWS641 radio-controlled Sun-Wind-Set hand-held transmitter with sensor 1. Programming the master 2x click transmitter Switch off the power supply on the radio receiver (drive type PSF(+)) and then switch it back on . Press the programming button on the master transmitter until the drive clicks twice...
  • Page 143 Use the tool provided to turn the wind threshold regulator to the desired setting. The wind threshold has 11 possible settings (approx. 2m/s to 22 m/s). When slowly turning the regulator, the tubular drive clicks to indicate the setting changes.

  • Page 144: Sc211 Control Unit

    SC211 control unit Commissioning of the SC211 awning radio-controlled movement sensor 1. Programming the master 2x click transmitter Switch off the power supply on the radio receiver (drive type PSF(+)) and then switch it back on . Press the programming button on the SWC241-II master transmitter until the drive clicks twice...
  • Page 145 Use the tool provided to turn the wind threshold regulator on the SWC241-II to the desired setting. The wind threshold has 11 possible settings (approx. 2 m/s to 22 m/s). When slowly turning the regulator, the tubular drive clicks to indicate the setting changes.

  • Page 146: Vc470-Ii Control Unit

    VC470-II control unit Commissioning Wiring Mains Drive The external radio receiver VC470-II can be used to convert conventional drives for venetian blinds, awnings and roller shutters to radio drives. Mains The Hirschmann STAS 3 connector is used as the connection at the drive and the Hirschmann STAK 3 cou- pling is used as the connection to the mains supply.
  • Page 147 Functions of the VC470-II 3. Programming the interme- diate position/tilt position Run the venetian blind out of the upper limit position to the required intermediate position then press the STOP and DOWN button until the drive shifts to acknowledge the programming operation.

  • Page 148: Centronic Radio Technology

    Centronic radio technology Operating principle: Single, group and central control unit configuration Each radio receiver has one storage space for a master transmitter and 15 storage spaces for additional transmitters. Master transmitter 15 additional transmitters The master transmitter is programmed in the receiver via the radio programming but- ton/radio switch or by switching on the power.
  • Page 149 In the case of 5-channel transmitters, each channel behaves like a separate trans- mitter. If all of the channels are selected (all group LEDs light up), all of the receivers programmed into the transmitter are activated. Example: Channel 1 - "Single transmitter A" (master transmitter) controls drive 1 Channel 2 - "Single transmitter B"...
  • Page 150 Centronic radio technology Programming the transmitter Programming the master transmitter Switch the mains voltage at the radio receiver (radio drive or external Cen- tronic radio receiver) back on (power on) or switch the radio switch of the radio drive to the position or press the radio programming button of the 1x click...
  • Page 151 Programming more transmitters 1x click Press the programming button on the master transmitter for 3 seconds until the radio drive clicks once or the external radio receiver moves briefly once. Then press the programming button 1x click at the transmitter to be reprogrammed for 3 seconds until the radio drive clicks once...
  • Page 152 Centronic radio technology Deleting the transmitters Deleting individual transmitters 1x click Press the programming button on the master transmitter for 3 seconds until the radio drive clicks once or the external radio receiver moves briefly once. 1x click Then press the programming but- ton on the transmitter to be deleted for 3 seconds until the radio drive...
  • Page 153 Deleting all transmitters (except 1x click the master transmitter) Press the programming button on the master transmitter for 3 seconds until the radio drive clicks once or the external radio receiver moves briefly once. Press the programming button on 1x click the master transmitter again for 3 seconds until the radio drive...

  • Page 154: B-Tronic Radio Technology

    B-Tronic radio technology Operating principle: Single, group and central control unit configuration Central transmitter S1 controls drive A1, A2 and A3 Group transmitter S2 controls drive A2 and A3 Single transmitter S3 controls drive A3 The transmitter is stored in the drive memory and the drive is stored in the transmitter memory by means of bidirectional programming (linking).
  • Page 155 Master mode In order to perform "Becker-specific" 1x click settings, e.g. programming of limit positions, the receiver must be put in the master mode. Switching on master mode Press the master button on a transmitter that has already been programmed...
  • Page 156 B-Tronic radio technology Programming (linking) transmitters Putting drive into programming mode By switching the power on Switch on the mains voltage at the B-Tronic radio drive Via the switch on the drive Switch the radio switch of the B-Tronic radio drive to the posi- 1x click tion.
  • Page 157 Clearing (unlinking) transmitters Putting drive into clearing 1x click mode 1x click Press the master button on an already 1x click programmed transmitter repeatedly until the required drive clicks once . Then press the programming but- ton on the same transmitter until the drive clicks once .
  • Page 158 B-Tronic radio technology Deleting all transmitters in the drive Putting drive into clearing 1x click mode 1x click Press the master button on an already 1x click programmed transmitter repeatedly until the required drive clicks once . Then press the programming but- ton on the same transmitter until the drive clicks once...
  • Page 159 Deleting all receivers in the hand-held transmitter that are not responding "Cleaning up" the memory in the hand-held transmitter You can delete specific receivers that are no longer responding but are still registered in the memory of the hand-held transmitter. Make sure that you are within range of all responding receivers.
  • Page 160 Technical data, rated torque and service life can be found on the type plate of the tubular drive. • Moving parts of drives must be installed at a height of over 2.5 m above floor level or any other surface from which access to the drive is gained.
  • Page 161 Keep people out of the system’s range of travel. • Only use in dry rooms (exception: VCJ470, VC410, VC510, SWC510). • Only use original, unmodified Becker parts. • Observe all pertinent country-specific regulations. • Dispose of exhausted batteries properly. Only replace batteries with the same type.
  • Page 162 BECKER-Antriebe GmbH Friedrich-Ebert-Str. 2-4 35764 Sinn, Germany Tel.: +49(0)2772/507-0 Fax: +49(0)2772/507-151 info@becker-antriebe.com www.becker-antriebe.com 4995 900 070 1 Version: 07/2017...

This manual is also suitable for:

RRf+Prf+Pr+RpProf+ ... Show all

Table of Contents
