Part 1 – Introduction

Installation

• Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall off if the wall or
ceiling is not strong enough to support its weight.
• Install the camera in a shaded area. If the camera
is installed in direct sunlight, it may be affected
adversely.
DC-D4533RX
1
Use the screws, anchor provided with the camera to
secure the install bracket on a wall or a ceiling.
Use the provided guide pattern to check the
distance between the screws.
2
Connect external devices, the network cable, and
the power adapter.
3
Adjust the angle. For more information, refer to the
Angle Adjustment.
14
DC-D4533HRX
1
Push the network cable through the cable rubber,
using the protective connector provided.
Cable rubber
2
Assemble the cable rubber to the bottom cover.
3
Attach the enclosed desiccant in the bottom to
prevent moisture.
Desiccant
Protect
Cable
connector
