Specifications

These product specifications may change without prior notice.
Video
Image Sensor
Max. Resolution
Scanning Mode
Lens type
Focal Length
Aperture
Iris Control
Angular Field of 5M (2592 x
View 1944)
4M (2592 x
1456)
Min. Illumination
Dynamic Range
Electronic Shutter Speed
Day & Night
IR Distance (LEDs)
Pan/Tilt Range
1/2.8" CMOS
2592 x 1944 (4:3)
2592 x 1456 (16:9)
Progressive Scan
Motorized Vari-focal
f=3.0 - 13.5mm
F=1.4 ~ 3.2
DC Iris
H: 91° (Wide) ~ 31° (Tele)
V: 66° (Wide) ~ 23° (Tele)
D: 120° (Wide) ~ 38° (Tele)
H: 91° (Wide) ~ 31° (Tele)
V: 49° (Wide) ~ 17° (Tele)
D: 107° (Wide) ~ 35° (Tele)
COLOR : 0.1 lux @ F1.4
B/W : 0 lux (IR LED ON)
120dB, True WDR
Auto / Manual (1/30 ~ 1/10,000), Anti-Flicker, Slow Shutter(1 ~ 1/5, 1/7.5, 1/15)
IR cut filter with auto switch
DC-D4533HRX
30m (6ea)
DC-D4533RX
20m (6ea)
Pan: -175° ~ 175°, Tilt: 0° ~ 67°, Rotate: -177° ~ 177°
