3.1.2 On-Board Connectors
The following table describes the interface connectors on the SAMA5D2-ICP.
Table 3-2. SAMA5D2-ICP Board Interface Connectors
Connector Interfaces to
J1 External power jack
J3 PMIC Vout4
Used for one-time programming of the
J4
EtherCAT EEPROM
J5 Standard SDMMC connector
J6 Dual CAN
J7 Stacked USB type B (USB hub)
J8 Stacked USB type B (USB hub)
J9 USB Micro-AB (USB-A)
J10 Ethernet 10/100/1000 RJ45 (HSIC)
J11 Ethernet 10/100 RJ45 (Etherswitch Port1)
J12 Ethernet 10/100 RJ45 (Etherswitch Port2)
J13 EtherCAT RJ45 port A
©
2020 Microchip Technology Inc.
Connector Interfaces to
J14 EtherCAT RJ45 port B
PCB connector for factory-programming
J15
the J-Link-OB
J16 USB Micro-AB J-Link-OB/J-Link-CDC
J18 JTAG, 10-pin IDC connector
J21 mikroBUS1 connector
J22 mikroBUS2 connector
J23 mikroBUS3 connector
J24 Tampers and PIOs
J25 WILC3000 UART debug
J26 WILC3000 user-free GPIOs
J27 ETH switch user-free GPIOs
