2.2

SAMA5D2-ICP Kit Content

The SAMA5D2-ICP kit includes the following:
• one SAMA5D2-ICP board
• one USB male A to USB male Micro-B cable
2.3

Evaluation Kit Specifications

Table 2-2. Evaluation Kit Specifications
Characteristic
Board
Board supply voltage
Temperature
Relative humidity
Main board dimensions
RoHS status
Board identification
2.4

Power Sources

Two options are available to power up the SAMA5D2-ICP board:
• Through an external AC to DC +5V wall adapter connector (J1 – default configuration)
• Through the USB Micro-AB connector on the J-Link-OB Embedded Debugger interface (J16)
Table 2-3. Electrical Characteristics
©
2020 Microchip Technology Inc.
Specification
SAMA5D2-ICP
External and USB-powered
Operating: 0°C to +70°C
Storage: –40°C to +85°C
0 to 90% (non-condensing)
150 × 100 × 20 mm
Compliant
SAMA5D2-ICP Industrial Connectivity Platform
Electrical Parameter
Input voltage
Maximum input voltage (limits)
Maximum DC 3.3V current available
I/O voltage
User Guide
ATSAMA5D2-ICP
Product Overview
Value
5VCC
6VCC
1.2A
3.3V only
