Secure to Ground

IMPORTANT: The greenhouse must be firmly secured to the ground. Make
!
sure the foundation is FLAT and LEVEL. Make sure the greenhouse is square.
The two diagonal measurements inside the greenhouse should be identical.
15
From the inside of the greenhouse, insert the S34 anchor clips into channels of side profile
G01C at each corner and center of both sides. Place the S35 pegs through the holes and into
the ground to establish proper placement. Remove the pegs, dig holes 12"/30cm deep and
fill with concrete. When the concrete is partially dry, use a hammer to drive the pegs all the
way into the concrete and let dry completely for twenty four hours.
G01C
S34
VIEW FROM INSIDE.
www.stcny.com
NOTE: Insert S34 anchor clips into the channel of side profiles
G01C at a slight angle and slide under the lip of the channel.
G01C
S35
49 of 50
Anchor Clip
QTY
#S34 6
Anchor Peg
QTY
#S35 6
