STC Clear View Assembly Instructions Manual page 12

1.8A
Slide hex bolt S13 into channels of profiles G05B as shown.
S13
G05B
1.9A
Remove protective plastic from both sides of panels GY3, GY4, GY7 and GY8. The clear panels are
designed with window shapes that curve outward. Place the outward curved side facing down. The
first row of ribed edges fit securely into the V-channels.
Fit panel GY3 into V-channel of profile G05B.
G05B
1.9C
Slide panels GY4, GY7 and GY8 into V-channels
on profiles G02A, G02B, G03C and G03D. Fit inside
V-channels on profiles G05B, G17C and G17D.
GY7
GY4
G02B
G03C
www.stcny.com
1.8B
Screw hex nut S14 onto bolt. Do not
completely tighten.
G05B
GY3
GY8
G03D
G02A
G05B
Profile
#G05B
!
Remove protective plastic from EACH side of clear
panels before installing. Dispose of plastic properly.
Install with outward curved side FACING DOWN.
1.9B
Slide GY3 into into V-channels on profiles
G03C and G03D. Continue to slide until
the ridges on the bottom edge fit into
bottom profile G01B.
G03C
Clear Panel
#GY3
#GY4
10 of 50
S14
Bolt/Nut
QTY
#S13
1
#S14
GY3
G03D
G01B
Clear Panel
QTY
1 #GY7
1
#GY8
QTY
2
2
QTY
1
1
