MES SQA-V Gold Service Manual page 31

and
8. Remove the dust sleeve by unscrewing 2 Phillips screws (fig. 10).
9. Gently clean the CCD using lint free microfiber cloth (fig. 11).
10. Attach the dust sleeve back to the CCD board and fasten 2 Phillips screws through
11. Carefully align the false track tool with the metal guide rail and gently push the CCD
12. Re-install the black stopper to the bench and fasten the screws.
13. Re-connect the internal and external video cables.
14. Assemble the lid on the base of visualization system and fasten the screws.
15. Assemble the DC motor, and make sure the cogwheel teeth coincide with the teeth of
16. Re-attach the visualization system back to the front panel.
Instructions 17. Replacing the CCD camera (no image on both SQA-V and V-sperm)
for all range
1. Follow the instructions for CCD cleaning, but this time do not remove the dust sleeve.
of SQA-V's
2. Using a Phillips screwdriver remove the four screws holding the camera PCB.
serial
3. Replace the defective CCD camera with a new one.
numbers
4. Fasten the four screws holding the CCD camera.
5. Follow the rest of instructions to finish the assembling of the visualisation system and
Video screen 18. Video screen (Part# LCD-0010)
ISSUE: The image on the Video Screen is wavy
Note: 1. Open the SQA-V device
This repair can
2. Disconnect the video screen cable from Control board
only be
3. Using a Phillips screwdriver, remove the screws holding the PCB of the video screen
performed for
4. Remove the hollow spacers holding the Video screen
SQA-V of SN
5. Replace the defective video screen with new one
1505 and
6. Re-assemble the spacers
above. For
7. Using a Phillips screwdriver, secure the PCB of the video screen with the screws
systems with
8. Connect the video cable of the new video screen
different serial
numbers, 9. Close the SQA-V
please contact
MES support
services.
SQA-V
Service Manual Dec_2019
Fig. 10
designated holes in CCD tray
tray back over the guide rail.
the white plastic rack.
re-attach it to the front panel.
Disconnect the Video screen
cable
Fig. 11
31
Remove the screws
