This Quick Start Guide provides the user with instructions for final set-up of the SQA-V /V-Sperm

Pro. It is assumed that the V-Sperm Pro software has already been installed on a computer and the

versions of the SQA-V Pro and V-Sperm Pro are as noted above.

•

Thermal Printer - Paper roll placement instructions

•

Open the top cover of the printer

•

The paper roll is placed on the reverse side

•

Cover the top lid of the printer so that the paper is slightly exposed

Note: Before installing the paper, please tear off the adhesive tape attached to the edge of the paper roll.

Q U I C K

(Pro 89.02/114.02)

SQA-V_V-Sperm Pro Quick Start Guide_15_Aug_19

S T A R T G U I D E

And

(Pro 88.0/115.03)

Need help?

Do you have a question about the SQA-V Gold and is the answer not in the manual?

Page 1 Q U I C K S T A R T G U I D E (Pro 89.02/114.02) (Pro 88.0/115.03) This Quick Start Guide provides the user with instructions for final set-up of the SQA-V /V-Sperm Pro. It is assumed that the V-Sperm Pro software has already been installed on a computer and the versions of the SQA-V Pro and V-Sperm Pro are as noted above.
Page 2 • Begin by establishing the connection between the PC and the V-Sperm Pro: • Plug the black power cord into the rear panel of the SQA-V Pro and into an electrical outlet. • Connect the RS-232 cable from the PC to the rear panel of the SQA-V Pro or use the RS-232 to USB convertor to connect the SQA-V Pro Device to the PC.
Page 3 • Conc./Chamber Standard 1 or 2 • LES select 1US or 2ROW • Printing options: automatically print test results/self test report on start-up. • Morphology Criteria: WHO 3rd or WHO 4th (in V-Sperm Pro 115.03 system only) • Control Set-up (from the manufacturer’s labeling): •...
