1.2 Specification

1.2.1 General

Construction： Heavy-duty steel chassis, hardened aluminum
alloy front panel
LCD：
Display Type: 15" TFT LCD active matrix
Resolution: 1024 x 768
Luminance: 250 cd/m2
Contrast Ratio: 150:1
Viewing Angle (Degree):
Backlight MTBF: 25000 hours
Drive Capacity： Expose 1 x 5.25", 1 x Built-in 3.5" FDD, and
Data Entry： Sealed membrane programmable keypads
- 60 data-entry keys & 24 function keys
LCD interface： VGA
Front Panel I/O： Two USB, one keyboard/mouse port, power
Front Panel controls：Brightness adjustment and Backlight on/off
Maximum acceptable card size： 185 mm x 122 mm
Cooling system： One 18cm ball bearing fan
Dimensions： 482.8mm(W) x 354.8mm(H)x 256mm(D)
Weight： 44 lbs (20kg)
Passive Backplane：
ATX6022/8GP7 7 PCI slots Support AXIOMTEK PCI Full/Half-size
ATX6022/8 4 PCI & 3 ISA slots Support AXIOMTEK Full/Half-size
Introduction
90° (V), 120° (H)
internal 2 x 3.5" drive
switch
CPU Card
CPU Card
