ICS-415V User's Manual

3.3 Driver Installation- DOS

3.3.1 Install PenMount software driver.

1. Insert Driver CD and select the \ICS series\ICS-415V\Driver\Touch
screen\DOS\ Install.exe
2. Press ENTER key to install the drivers to drive C or use keyboard
to key-in the hard disc drive that you plan to install the driver.
3. The driver will ask "Do you want to modify your Autoexec.bat to
initialize PenMount? (Y/N)" Suggest you choose "YES" for
generating the initialization instructions in AUTOEXEC.BAT files.
Then follow up the instructions to complete the installation.

3.3.2 Communication port and IRQ number

1. For the first time installation, or changing PenMount Touch
Screen's COM port, use PMDETECT (e.g.
C:\PENMOUNT\PMDETECT) to check the COM port and IRQ
number. PMDETECT will save the correct data to PMOUSE.CFG
file for further use.
The driver detects your communication COM port and IRQ number
from COM1 IRQ4, COM2 IRQ3, COM3.... to COM4 IRQ15. PenMount
driver can find the COM port and IRQ number automatically. The
screen will then show:
PenMount is initialized successfully!!!
Create file "pmouse.cfg". Success.
PenMount internal settings:
Comm. Port: COM<n> IRQ<n>
..........
1. PMDETECT program is able to skip the IRQ number detecting if
you Touchscreen Driver Installation 13 do not need to detect the
specified IRQ number. For example, you do not need to detect
IRQ5, and the command is:
C:\PENMOUNT\PMDETECT -N5
If you do not need to detect IRQ5 and IRQ9, the command is:
32
Touch Screen Driver Installation
