A M P R E S E A R C H P O W E R S T E P
Remove passenger lower trim under the glove compartment as shown in the following two steps.
Wire connector
plastic fastener
A. remove the three plastic fasteners with
a soft pry tool.
15
Now using an 1/8" drill bit, drill a hole in the specified area shown
below. Make hole bigger by using a 9/32" drill bit.
16
Use a lubricant on the two purple wires provided with the wire harness (7). Starting from the passenger
lower compartment feed each wire thru the grommet up to the engine compartment. Make sure to feed one
wire at a time, and pull wires careful to prevent grommet from coming out.
18
www.amp-research.com
– D O D G E D U R A N G O
T M
plastic fastener
plastic fastener
B. Using a soft pointed tool, push the tab on the wire
connector in, then carefully pull the top part of the con-
nector up to release it. (see example in box above)
Install Grommet (26) in hole.
Note: It is very important to add the
grommet, as damage may occur if
wires get stripped from rubbing on the
sharp metal of the hole.
Drill here
17
8/13
Wire Connector Example
Push tab in
Pull up
26
7
IM76331 rev 8.10.18
