9.9 Additional examples

9.9.1 Gaussian envelope
The following example demonstrates creation of a short (300 ns)
Gaussian pulse by specifying the output power at the maximum up-
date rate (instruction duration 0 1 = 16 ns). The resulting output
waveform is shown in Figure 9.5.
# set up table mode
MODE,1,TPA
TABLE,CLEAR,1
TABLE,XPARAM,1,POW
# define points along Gaussian
TABLE,APPEND,1,POW,-24.59dBm,0x1
TABLE,APPEND,1,POW,-22.08dBm,0x1
TABLE,APPEND,1,POW,-18.88dBm,0x1
TABLE,APPEND,1,POW,-14.99dBm,0x1
TABLE,APPEND,1,POW,-10.53dBm,0x1
TABLE,APPEND,1,POW,-5.74dBm,0x1
TABLE,APPEND,1,POW,-0.95dBm,0x1
TABLE,APPEND,1,POW, 3.41dBm,0x1
TABLE,APPEND,1,POW, 6.92dBm,0x1
TABLE,APPEND,1,POW, 9.21dBm,0x1
TABLE,APPEND,1,POW,10.00dBm,0x1
TABLE,APPEND,1,POW, 9.21dBm,0x1
TABLE,APPEND,1,POW, 6.92dBm,0x1
TABLE,APPEND,1,POW, 3.41dBm,0x1
TABLE,APPEND,1,POW,-0.95dBm,0x1
TABLE,APPEND,1,POW,-5.74dBm,0x1
TABLE,APPEND,1,POW,-10.53dBm,0x1
TABLE,APPEND,1,POW,-14.99dBm,0x1
TABLE,APPEND,1,POW,-18.88dBm,0x1
TABLE,APPEND,1,POW,-22.08dBm,0x1
TABLE,APPEND,1,POW,-24.59dBm,0x1
TABLE,ARM,1
Listing 9.8: Rapid Gaussian pulse (340ns) in fast table mode
