C.9 Table mode
C.9 Table mode
ARM
START
STOP
REARM
Table mode gives access to the powerful sequencing functionality of
the / devices (chapter 8).
ARF XRF
advanced table mode (chapter 9), which is controlled using the same
TABLE
commands.
TABLE,ARM,ch
Loads the table into the
The table then begins execution upon receiving a software trigger
TABLE,START
( ) or hardware trigger on the
Note: The table length must be defined before issuing
failure to do so may result in undefined behaviour. The convenience
TABLE,APPEND
functions (e.g.
TABLE,START,ch
Provides a software trigger to initiate table execution. Calls
if the table is not already ready for execution, which can cause a
short delay before output appears.
Early 421-series models may encounter an error that the amplifiers
are disabled when using this command. The recommended solution
is to manually power-on the amplifiers earlier using either
TABLE,ARM
or before the
TABLE,STOP,ch
Terminates an executing table at the end of the current step. Note
output will remain on, holding the instruction being
that the RF
executed when the command was received, until the table is rearmed
or the output disabled with the
TABLE,REARM,ch[,on/off]
Enables/disables the automatic re-arming (loading) of the table
upon completion such that it can be started again without using
ARM
the command. Table will then begin executing upon a software
or hardware trigger.
devices also have access to
XRF
for execution, typically taking ∼ 100 s.
FPGA
) automatically update the table length.
TABLE,START
command.
OFF
command.
DE15 connector (§7.1).
ARM
or
TABLE,ARM
ON,1,POW
109
