2.2 Rear panel controls and connections

90-264 Vac
47-63 Hz
IEC power in
Fan
RF OUT
MON
AM/FM/PM
CLK IN
DE15
RF OUT 1
MON 1
The is compatible with all standard
ARF
to 264 V and 47 to 63 Hz. The maximum current draw is about 1 A.
The ARF has three temperature-controlled fans directing air flow over
the power amplifiers and the
RF
vent. Ensure that the vent does not become blocked.
SMA connectors for the primary
a 50Ω load. Must not be short-circuited.
SMA connectors for "monitor"
of the main output (when high-impedance terminated).
analog inputs, nominally for frequency and amplitude modu-
SMA
lation (see chapter 5). These inputs can also be used for laser
noise-eater or frequency stabilisation applications (see chapter 6).
The can be synchronised to a high-performance external clock
ARF
input via this SMA
The input is 50 Ω terminated, and the provided reference must be
between 10 and +10 dBm (preferably square-wave).
The DE15 connector provides basic I/O functionality (§7.1). There
are TTL inputs for quickly suppressing the
for controlling experimental devices such as shutters. Two general-
purpose analogue outputs are also available for monitoring purposes.
Chapter 2. Connections and controls
FM/PM 1 FM/PM 2
RF OUT 2
AM 1 AM 2
MON 2
FPGA
RF outputs. Should be connected to
RF outputs, which are
connector and software commands (see §C.8).
CLK IN
Model:
Serial No:
power systems, from 90
AC
, exhausting through the rear
20 dBc copies
RF output, and TTL outputs
