8.2 Defining table entries
TTL trigger on the
The phase-accumulator of the
cutes autonomously under
degree of reproducibility in terms of both timing of instructions and
output of the DDS generators, as the
for every execution.
The table can be automatically restarted after completion by en-
TABLE,RESTART
abling the
sequence using the
Each channel has its own independent table, and there are slots for
four distinct tables in non-volatile memory. Commonly-used tables
can then be stored on the device for later use. However, it should
be noted that stored tables may become inoperable after a firmware
upgrade and tables should be archived in human-readable form.
When a table is armed, the
fiers for 421-models), and upon completion of the table the final
state remains ongoing. If it is required that the output be disabled
when the table is complete, the final entry should set the power to
0x0 (zero amplitude, not 0 dBm).
Table entries can be defined or queried using the
mand. Once the entries have been set, the
mand should be used to set the length of the table. Alternately, the
TABLE,APPEND
command can be used to add an entry to the end of
the table and update the count automatically.
It is recommended to always explicitly empty the table with the
TABLE,CLEAR
command before defining the entries.
2
On R 2 units, the ON pin is used instead.
Chapter 8. Simple table mode
2
SEQ input or using the
DDS is then reset and the table exe-
FPGA control. This provides a very high
DDS
option, and execution can be stopped mid-
TABLE,STOP
command.
is switched on (including the ampli-
RF
TABLE,START
command.
phase accumulator is reset
TABLE,ENTRY
TABLE,ENTRIES
RF
com-
com-
