Electrical Connector Kit Parts; Air Purge Screw Kit Parts - Red Jacket Quick-Set VSFC Submersible Turbine Pump Installation, Service, & Parts Lists

Parts Lists

Electrical Connector Kit Parts

Table 15 lists the 410165-001 Electrical Connector Kit parts list.
Item
(ref. Figure 52)
1
2
3
4

Air Purge Screw Kit Parts

Table 16 lists the 410484-001 Air Purge Screw Kit parts list.
Item
(ref. Figure 53) Part No.
1 410064-001
2 410134-002
3 579005-007
4 579005-009
5 579014-002
Table 15. 410165-001 Electrical Connector Kit Parts List
Part No.
113-640-4 Connector - male
410117-001 Connector - electrical
072-541-1 O-ring - 118 - FKM
072-214-1 Ring - internal lock - 5/8" ID x 7/8" OD
1 1
4 4
Figure 52. Electrical Connector Kit
Table 16. 410484-001 Air Purge Screw Kit Parts List
Description
FKM
O-ring-015-
Screw - air purge - SST
FKM
O-ring-014-
FKM
O-ring-903-
Clip - hitch pin clip- SST
Description
2 2
rjpumps\fig54.eps
Qty.
1
1
1
1
5
1
54
Electrical Connector Kit Parts
Qty.
1
1
1
1
3 3
1
4 3
2
Figure 53. Air Purge Screw Kit
