Siphon Cartridge Kit Parts; Check Valve Housing Kit Parts - Red Jacket Quick-Set VSFC Submersible Turbine Pump Installation, Service, & Parts Lists

Parts Lists

Siphon Cartridge Kit Parts

Table 8 lists the 410151-001 Siphon Cartridge Kit parts list.
Table 8. 410151-001 Siphon Cartridge Kit Parts List
Item
(ref. Figure 46) Part No.
1 410255-001

Check Valve Housing Kit Parts

Table 9 lists the 410152-001 Check Valve Housing Kit and 410152-001 High Pressure Check Valve Housing Kit
parts lists.
P/N 410152-001 Check Valve
Housing Kit Parts List
Item
(ref. Figure 47) Part No.
1 410016-001
2 410027-001
3 410022-001
Description
Siphon assembly
Table 9. Check Valve Housing Kits Parts Lists
Description Qty.
Housing assembly -
chk/rlf vlv 1
Spring 1
Poppet assembly -
chk/rlf vlv 1
1 1
j
Figure 47. Check Valve Housing Kit
Qty.
1
P/N 410152-002 High Pressure Check Valve
Housing Kit Parts List
Item
(ref. Figure 47) Part No.
410016-
1 001
410027-
2 001
410022-
3 002
2 2
\fi 50
50
Siphon Cartridge Kit Parts
rjpumps\fig49a.eps
Figure 46. Siphon Cartridge Kit
Description
Housing assembly -
chk/rlf vlv
Spring
Poppet assembly -
chk/rlf vlv
3 3
Qty.
1
1
1
