Parts Lists

Customer Service Number

After unpacking the equipment, please inspect the parts. Make sure all accessories are included and that no
damage occurred during shipping. Report any damage to the shipper immediately and inform a customer service
representative at 1-800-873-3313 of any equipment damage or missing parts.

Pump Parts

Table 7 lists the pump parts list.
Item
(ref. Figure 45)
1
2
2
2
2
2
2
3
—
—
—
—
Table 7. Pump Parts List
Part No.
410156-001 20 ft. pigtail
852-209-5 UMP200U20-2
410184-027 UMP200U20-2 w/2" DH and pigtail
852-210-5 UMP200U20-2 w/FSA
852-175-5 AGUMP200T20-2
410184-028 AGUMP200T20-2 w/2" DH and pigtail
852-181-5 AGUMP200T20-2 w/2" FSA
144-327-4 Kit - flex siphon/UMP (includes gasket, lock washers and bolts)
144-194-5 Trapper - retrofit (not shown)
410161-001 Conduit adaptor assembly
410219-001 PACMAN - P200U20-2 20% w/ Conduit adaptor assembly
410219-002 PACMAN - AGP200T20-2 w/ Conduit adaptor assembly
Description
48
DOM
1
1
1
1
1
1
1
1
1
1
1
1
